MAX15303 PMBus Command Set User’s Guide
Page 46 of 52
STRAP_DISABLE
16 VOUT_TRIM
No function; intended to support a possible pin-strap voltage
trimming scheme that was never implemented.
15 INTERLEAVE
Command set indirectly by the SMBus slave address, from
R
ADDR0
and R
ADDR1
resistor values.
14 COMP_MODEL
The F
LC
data is set automatically by the parametric extraction
process
13 VOUT_MAX Command set indirectly according to VOUT_COMMAND x 110%
12 IOUT_CAL_GAIN Command set by R
ADDR1
resistor value
11 FREQUENCY_SWITCH Command set by R
SYNC
resistor value
10
9 IOUT_OC_FAULT_LIMIT Command not set automatically; flag is for future sue
8 VOUT_MARGIN_LOW Command set indirectly according to VOUT_COMMAND x 95%
7 VOUT_MARGIN_HIGH Command set indirectly according to VOUT_COMMAND x 105%
6 POWER_GOOD_OFF Command set indirectly according to VOUT_COMMAND x 85%
5 POWER_GOOD_ON Command set indirectly according to VOUT_COMMAND x 90%
4 VOUT_UV_WARN_LIMIT Undervoltage warning is not implemented
3 VOUT_UV_FAULT_LIMIT Command set indirectly according to VOUT_COMMAND x 85%
2 VOUT_OV_WARN_LIMIT Overvoltage warning is not implemented
1 VOUT_OV_FAULT_LIMIT Command set indirectly according to VOUT_COMMAND x 115%
0 VOUT_COMMAND Command set by R
SET
resistor value
