Installation & Loading Instructions - Please Read Before Beginning
Installation without cross bars, see instructions 1-9. Installation with cross bars, see instructions 10-17.
1
3
. Place the SUP onto the Blocks so that the
bottom of the board is facing up. Align the
SUP so it’s weight is evenly distributed on
the two Blocks. See Image 2.
. Place the Spacer Pads on top of the SUP so that
they are aligned with the Blocks. Dress the
two Block Straps over the Pads. Dress the Strap
free ends through the buckles and tighten.
See Image 3.
NOTE: The Spacer Pads are only required
when transporting two SUP’s.
22” Spacer Pads 15’ Load Straps 9’ Block Straps 24” SUP Blocks
P
ADDLEBOARD
D
ELUXE
C
ARRIER
MPG171 R
OOF
T
OP
SUP B
OARD
T
RANSPORT
K
IT
Installation without Cross Bars
. Unroll the two 9’ Block Straps. Thread a Strap
through the cut-out in the bottom of a 24” Block.
Repeat for second Strap and Block. Measure
the SUP. Position the Blocks so they are aligned
and spaced apart approximately 1/3 of the total
length of the SUP. See Image 1.
2
Bottom of Board
