Installation & Loading Instructions - Please Read Before Beginning
1
2
3
SeaWing
SeaWing
TM
V-STYLE KAYAK CARRIER
. Insert Mounting Bolt through one hole of a
Jawz Mounting Adapter and loosely apply
a T-knob. See image 2.
Step 1: Installing Carriers to Cross Bars
. Insert a Mounting Bolt into one of the top side hex
holes. See image 1.
. Place the carrier onto the front cross bar. Swing
the Jawz under the cross bar as shown.
See image 3.
12’ Safety Lines
MD Series Only
Jawz Universal Adapters
Mounting Bolts
60mm
50mm
SeaWing Kayak Carriers
12’ Load Straps
T-Knobs
Rubber Plugs
