Installation Manual
5
M4-ExTENSiON LAYOUT
LAARS Modulating Controls M4 & M4-EXT
HT# 059104-00 B
ENCLOSED
ENERGY
MANAGEMENT
EQUIPMENT
99RA
F
H
J
Power
CAUTION:
Risk of Electric Shock.
More than one disconnect switch may be required
to de-energize the equipment before servicing.
PWR
L N
1 2
E
3 4
F
5 6
G
7 8
H
9 10
I
11 12
EXTENSION
MODULE
RS-485
Ext A
INPUT RATINGS:
115VAC 60Hz, 12VA MAX
Use Copper Conductors Only.
OUTPUT RATINGS:
120VAC, 6A RESISTIVE
1A PILOT DUTY, 15A TOTAL
FOR ALL CIRCUITS
E
G
I
Comm
Ext B
K
M
O
L
N
P
17
16
VLT
mA
CUR / VLT
20
19
16
VLT
mA
GND
CUR / VLT
23
22
19
VLT
mA
GND
CUR / VLT
26
25
22
VLT
mA
GND
CUR / VLT
J
13 14
K
M
O
L
N
P
E
F
G
H
K
M
L
N
15
GND
18
GND
21
GND
24
GND
29
28
VLT
mA
CUR / VLT
32
31
16
VLT
mA
GND
CUR / VLT
27
GND
30
GND
I
J
O
P
M4-Ext
FULL MODULATION SEQUENCING EXTENSION
ENCLOSED
ENERGY
MANAGEMENT
EQUIPMENT
99RA
120VAC Power
Six N.O. Boiler startup relay
outputs. Each is wired in series
with the boiler's limit circuit.
Six modulating outputs can be 0-5V,
0-10V, 1-5V, 2-10V, or 4-20ma. Go to
M4 or M4-CNC Startup Menu to
determine the type of output for each stage.
LED indicates the
associated relay status.
Connect to M4 or M4-CNC
and additional Extension panels to add
additional stages using phone style cable
(cable provided with M4-Ext).
Extension Selection Switch to determine
Stage letters and LED colors.
Ext-A Stages E - J and all LEDs are Green
Ext-B Stages K - P and all LEDs are Red
This switch is covered with the Wiring Enclosure.
