M4-CNC LAYOUT
LAARS Heating Systems
HT# 059104-00 B
FOR ALL CIRCUITS
120VAC, 6A RESISTIVE
OUTPUT RATINGS:
1A PILOT DUTY, 15A TOTAL
115VAC 60Hz , 12VA MAX
INPUT RATINGS:
USE COPPER CONDUCTORS ONLY
CAUTION
: RISK OF ELECTRIC SHOCK
More than one disconnect switch may be required
to de-energize the equipment before servicing.
ENCLOSED
ENERGY
MANAGEMENT
EQUIPMENT
99RA
SYSTEM
A
B
C
D
RUN
PROGRAM
12
13
15
14
17
16
18
22
20
19
21
24
23
-
+
+
mA
GND
VLT
CUR / VLT
A
-
+
+
mA
GND
VLT
-
+
+
mA
GND
VLT
-
+
+
mA
GND
VLT
+
mA
CUR / VLT
B
CUR / VLT
C
CUR / VLT
D
OD=
25
o
F
SYS=
145
o
F
<>
B
D
100%
52% ---
---
DO NOT APPLY ANY VOLTAGE
TO INPUT TERMINALS
29
25
27
26
28
32
30 31
T
T
O
O
TEMP
OUTDOOR
O
O
TEMP
SYSTEM
PROVE
/DHW
SHUTDOWN
/TSTAT
/SETBACK
1 2
3 4 5 6 7 8 9 10 11
L N
RS-485
SYS
A
B
C
D
PWR
EXTENSION
MODULE
M4-CNC
CONDENSING AND NON-CONDENSING
The digital display shows the System and Outdoor temperatures,
the lead stage and lead group <
each stage. To view and adjust settings, press the appropriate buttons.
120VAC Power
Four N.O. Boiler startup relay
outputs. Each is wired in series
with each boiler's limit circuit.
System Output controls
pumps, valves, or other
system components.
Four modulation outputs can be 0-5V,
0-10V, 1-5V, 2-10V, or 4-20ma. Go to
Startup Menu to determine the type of
output for each stage.
LED indicates the
associated relay status.
Button functions are presented on
Bottom Row of display.
When connecting Outdoor and System
Sensors, no Polarity is observed.
Prove terminals must be connected for
the M4-CNC to operate the boilers.
Connect Extension panels to
add additional stages using
a phone style cable (cable
provided with M4-Extension).
Program Switch to restrict access to
function changes. This switch is
covered with the Wiring Enclosure.
