Page 20: Switch differential
HT#
059295-00
A
20
M4-LHS Installation and Operation Manual
EMS 4mA and 20mA Set Points
4mA: can be set from 50°F/ 10°C to 200°F/93°C
Default: 70°F/ 21°C
20mA: can be set from 70°F/ 21°C to 220°F/104°C
Default:
220°F/ 104°C
Button: MENU/
• With the use of the 4-20mA EMS Interface, the M4-LHS will be able to receive a 4-20mA
signal as a set point from a BMS or an EMS system as the target set point.
• The 4mA and 20mA Set Point menus will follow the selection of the 4-20mA EMS sensor
