16 Second balance interface
When using as counting system, the platform must be connected with a suitable
cable via the second-balance interface.
All models except for CFS 50K-3:
9 pin d-subminiature bushing of the
balance Interconnection of platform KERN KFP
Pin no.: Balance connection
Pin 1 or 2 EXC+ (5V)
see labelling of load cell
Pin 4 or 5 EXC- (0)
Pin 7 SIG–
Pin 8 SIG+
Model CFS 50K-3:
Pin no.: Balance connection Connection platform
Pin 1 SIG+
see labelling of load cell
Pin 2 SIG–
Pin 3 not connected
Pin 4 EXC–
Pin 5 EXC+
