ABT-BA-e-1312 68
15.5.1 Communication speed settings
1. The display changes from “io.b:****” to “b-300”. Pressing the [CAL] key changes the
display. The standstill display ( ) marks the current setting.
Display during setting
b-300 b-600 b-1200 b-2400 b-4800
Setting specifics
300bps
Baud Rate
600bps
Baud Rate
1200bps
Baud Rate
2400bps
Baud Rate
4800bps
Baud Rate
Display during setting
b-9600 b-19.2K b-38.4K
Setting specifics
9600bps
Baud Rate
19.2Kbps
Baud Rate
38.4Kbps
Baud Rate
2. Confirm your desired setting by pressing the [TARE] key.
3. To return to "io.S:****", press the [ON/OFF] key.
15.5.2 Delimiter settings
1. The display changes from “io.d:****” to “d-Cr”. Pressing the [CAL] key changes the
display. The standstill display ( ) marks the current setting.
Display during setting
d-Cr d-LF d-CrLF d-Cn d-win 1 d-win -
Setting specifics
C/R L/F C/R + L/F Comma Not documented
2. Confirm your desired setting by pressing the [TARE] key.
3. To return to "io.d:****", press the [ON/OFF] key.
15.5.3 Parity settings
1. The display changes from “io.P:****” to “P-no”. Pressing the [CAL] key changes the
display. The standstill display ( ) marks the current setting.
Display during setting
P-no P-odd P-EvEn
Setting specifics
No parity
(eight bits)
Odd parity
(seven bits)
Even parity
(seven bits)
2. Confirm your desired setting by pressing the [TARE] key.
3. To return to "io.P:****", press the [ON/OFF] key.
