Wireless modem operation – Juniper Systems RTK GPS Expansion Pack User Manual
Page 3
RTK GPS Expansion Pack
The GPS receiver uses COM port 7 and COM port 8 with a
default of 9600 baud, 8 data, no parity, 1 stop bit.
GPS Antenna
For the GPS antenna, we recommend using the Novatel
dual frequency, dual constellation antenna model 702-GG.
Wireless Modem Operation
The following steps are required to get the GSM modem
ready to use (these steps are described in this manual):
Set up a wireless service data account for the GSM
modem and receive a SIM (Subscriber Identification
Module) card.
Install the SIM card in the wireless modem, and seal
the card portal.
Install the expansion pack and antennas on the
handheld.
Run the setup program to configure the wireless
modem.
CAUTION:
Damage to the RTK GPS expansion pack can
occur if it is installed or removed while the handheld in
running or in suspend. Ensure the handheld has been
completely powered off before installing or removing the
RTK GPS Expansion Pack. This is done by holding the
power button down until the power menu pops up and
selecting the Power Off option.
!!
