Page 37
37
Table 12 — Filter Data
*Only 2-in. filters are available on size 03.
39L UNIT SIZE
03
06
08
10
12
15
18
21
25
Angle Filter Section
Filter Qty…Size (in.)
2…16x25
4…16x20
2…16x20
2…16x25
4…16x25
6…16x20
9…16x20
12…16x20
4…16x20
8…16x25
4…16x20
8…16x25
Nominal Face Area (sq ft)
5.56
8.89
10.00
11.11
13.33
20.00
26.67
31.11
31.11
Filter Mixing Box Section
Filter Qty…Size (in.)
2…16x25
4…16x20
2…16x20
2…16x25
4…16x25
6…16x20
9…16x20
9…16x20
3…16x20
6…16x25
4…16x20
8…16x25
Nominal Face Area (sq ft)
5.56
8.89
10.00
11.11
13.33
20.00
20.00
23.33
31.11
Flat Filter Section
Filter Qty…Size (in.)*
2…16x16
2…20x20
2…20x25
2…16x25
1…20x25
3…20x25
6…16x20
3…16x20
3…20x20
3…20x25
3…16x25
2…16x20
2…20x20
2…20x25
2…16x25
Nominal Face Area (sq ft)
3.56
5.56
6.94
9.03
10.42
13.33
15.00
18.75
22.50
16”
20”
25”
16”
20”
25”
25”
25”
16”
20”
20”
SIZE 21
SIZE 25
Fig. 43 — Filter Arrangement, 2-in. and 4-in. Flat
