More pip (pictlre-in-pictlre) connections, Pip (p – Philips TP2785CI User Manual
Page 42
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
[^1
M
ore
PIP (P
ictlre
-I
n
-P
ictlre
) C
onnections
P
ip
hookup with a VCR and a
Digital Video Disc Player (or
similar device).
rr^rnn
<,1^ First connect the original cable
TV signal or Antenna signal to the
ANT IN jack on the back of the
VCR.
Connect the ANT OUT jack on
the rear of the VCR to the ANT IN
jack on the rear of the Video Disc
Player.
Connect the ANT OUT Jack on
the rear of the Video Disc Player to
the 75i2 input on the rear of the iV.
Connect the yellow Video Cable
from the VIDEO OUT jack on the
VCR to the VIDEO AVI jack on the
TV. Then, connect the red and white
Audio Cables from the AUDIO OUT
jacks on the VCR to the AUDIO AVI
jacks on the rear of the TV (labeled
AUDIO L& RAVI).
Connect tbe yellow Video Cable
from the VIDEO OUT jack on the
Video Disc Player to the VIDEO
AV2 jack on the TV, Then, connect
the red and white Audio Cables from
the AUDIO OUT jacks on the VCR
to the AUDIO AV2 jacks on the rear
of the TV (labeled AUDIO L & R
AV2).
Note: When selecting the PIP
SOURCE, the VCR will appear on
the EXT 1 channel, and the Video
Disc Player will appear on the EXT
2
channel.
REAR OF TV
OUTSIDE UHF/VHF
ANTENNA OR
CABLE TV SIGNAL
42
