Controls on the system and
remote control
[T] STANDBY ON
- to switch the system on or to standby
mode.
to use for EASY SET.
[ 2 ] DIGITAL SOUND CONTROL (DSC)
to select the desired sound effect:
OPTIMAL, CLASSIC, TECHNO. JAZZ,
ROCK or VOCAL.
[1 .iH
-
to connect headphones.
[ 4 ] JOG A orT
to select the desired equalizer display.
- to select the desired DSC setting. You
must select the DSC feature first.
[ 5 ] PROG (PROGRAM)
“ to program CD tracks in CD mode or to
preset radio stations in tuner mode.
[6] CLOCK/TIMER
to view the clock, set the clock or set
the timer.
[ 7 ] DISPLAY
- to view the current setting of the
system.
[
8
]
CD CAROUSEL TRAY
[9l CD DIRECT PLAY (DISCI/DISC 2/
DISCS)
- to select a CD tray for playback.
[m] DISC CHANGE
- to change CD(s).
[ij] OPEN*CLOSE
- to open or close the CD carousel.
mi
15
SOURCE : to select the following:
CD/(CD 1*2*3)
to select CD mode. When CD playback
is stopped, press to select the disc
tray 1,2 or 3.
TUNER/(FM*AM)
to select Tuner mode. When in Tuner
mode, press to select the waveband:
EM or AM.
TAPE/(TAPE 1*2)
to select Tape mode.
AUX/(VIDEO)
to select sound from an external
source (e.g. TV, VCR player. Laser Disc
player or DVD player).
TV (on FW748P remote control only)
to select TV mode.
DPL DISPLAY PANEL (forFW748P
only!
to view the selected Dolby Pro Logic
setting.
DOLBY PRO LOGIC (DPL) (for
FW748Ponly)
to select Dolby Surround, Dolby Center
Phantom, Dolby 3 Stereo or Stereo
mode.
MODE SELECTION
SEARCH ►► (TUNING ◄◄ ►►)
for CD..............to search backward/
forward.
for TUNER...... to tune to a lower or
higher radio frequency.
for TV VOL......to adjust the TV volume
if the remote operates
your TV (on FW748P
remote control only).
•CLEAR ■ [
CONTROLS
H TAPE DECK 1 OPERATION
............to stop CD playback or RECORD ....to start recording.
to clear a program. PLAY ► ........... ....to start playback.
^ER..... to stop programming. ◄◄.................... .... to rewind the tape.
...........(on the system only) to ►►.................... .... to fast forward the
start or stop tape.
demonstration mode. STOP*OPEN ....to stop playback/
► / PAUSE II recording or to
............to start or interrupt open the tape deck
playback. door.
N/NEXT N (PRESET T A) PAUSE ............. .... to interrupt
............to skip to the beginning playback or
of the current, previous. recording.
DEMO
for CD
for CD
or next track.
for TUNER...... to select a preset
station in memory.
(1 VOLUME
to adjust the volume.
[1 DYNAMIC BASS BOOST (DBB)
- to select a bass boost level or to
switch off bass boost.
51 TAPE DECK 2
TAPE DECK 2 OPERATION
PLAY ► ........
◄ ◄ ..................
► ► ..................
STOP*OPEN
PAUSE
. to start playback.
. to rewind the tape.
. to fast forward the
tape.
. to stop playback or
to open the tape
deck door.
. to interrupt
playback.
TAPE DECK 1
IS/VEC (available in model FW798W
only)
to switch on or off the surround sound
effect.
REPEAT
to repeat a CD track, a disc, or all
available discs.
SHUFFLE
to play all the available discs and their
tracks in random order.
SLEEP TIMER
to switch the system to standby mode
at a selected time.
BALANCE L/R (on FW748Premote
control only)
to balance the sound level of the Eront
Left and Right speakers.
REAR +/— (on FW748Premote
control only)
to adjust the sound level of the
surround speakers.
13
