Chapter 4: Console Management
GE-DS-242-PoE Managed Ethernet Switch User Manual 109
Figure 4-60: Access Control List (ACL) Web Page screen
This page includes the following fields:
IPv4 ACL
OBJECT DESCRIPTION DEFAULT VALUE
Group ID 1 ~ 247 (max. 247 ACL group).
Action Permit / Deny.
Permit: Permit packet cross switch.
Deny: Drop packet.
Permit
VLAN Any / VID.
Any: Any VLAN id.
VID: 1~4094. A certain VLAN id.
Any
Packet Type IPv4 / Non-IPv4 / Binding
IPv4: Set Ipv4 packet field.
Non-IPv4: Set non-Ipv4 packet field.
Binding: Set binding entry.
IPv4
