Chapter 4: Web-Based Management
108 GE-DS-242-PoE Managed Ethernet Switch User Manual
Figure 4-59 : QoS Configuration - TOS/DSCP Port Status
This page includes the following fields:
OBJECT DESCRIPTION
Port Number Indicate port 1 to port 26.
TOS/DSCP Status Enable / Disable TOS/DSCP map to 802.1p priority on specify port.
Access Control List
The Access Control List (ACL) is a concept in computer security used to enforce
privilege separation. It is a means of determining the appropriate access rights to
a given object depending on certain aspects of the process that is making the
request, principally the process's user identifier. Access Control List (ACL) is a
mechanism that implements access control for a system resource by listing the
identities of the system entities that are permitted or denied to access the
resource. The screen in following screen appears.
Packets can be forwarded or dropped by ACL rules include Ipv4 or non-Ipv4. The
Managed Switch can be used to block packets by maintaining a table of packet
fragments indexed by source and destination IP address, protocol, and so on.
Packet Type / Bindings can be selected to ACL for Ipv4 or Non-Ipv4.
