6
1.3 Product Specifications
Model MC252-1T-1CXP MC252-1P-1CX
Hardware Specifications
Copper
10/100Base-TX RJ-45
Auto-negotiation/
Auto-MDI/MDI-X
802.3at/af PoE Input 10/100Base-TX RJ-45
Auto-negotiation/
Auto-MDI/MDI-X
802.3at/af PoE Output
Coaxial
BNC, female
Power over Coaxial Output BNC, female
Power over Coaxial Input
DC Socket
(Optional)
52~56V DC Input
2-Position DIP Switch
 Selectable CO or CPE mode
(Default: CO)
 Selectable Band plan:
Asymmetric or Symmetric
(Default: Symmetric)
2-Position DIP Switch(Front)
 Selectable CO or CPE
mode (Default: CO)
 Selectable Band plan:
Asymmetric or Symmetric
(Default: Symmetric)
Interface
DIP-Switch
---
2-Position DIP Switch (Rear)
 PoE out or DC out (Default:
PoE out)
 12V DC / 24V DC output
voltage (Default: 12V DC)
LED Indicators
LED is Green Color
 PWR
 PoE IN
 LNK
 CO
 CPE
 LNK/ACT
 100
LED is Green Color
 PWR
 PoE IN
 PoE Out
 LNK
 CO
 CPE
 LNK/ACT
 100
ESD Protection 2KV DC
EFT Protection 2KV DC
Enclosure IP30 metal case
Installation Wall mount or DIN rail with optional kit
Dimensions (W x D x H) 94 x 70.3x 39.2 mm
Weight 288g 302g
Power Requirements
 RJ-45 PoE Input: 802.3at/af
44~57V DC
 DC Input: 52~56V DC
 BNC Power over Coaxial
Input: 44~57V DC
 DC Input: 52~56V DC
Asymmetric Mode (Data Only)
200m -> 100/65Mbps 800m -> 100/53Mbps
400m -> 100/64Mbps 1000m -> 94/44Mbps
600m -> 100/59Mbps 1200m -> 84/36Mbps
Symmetric Mode (Data Only)
Performance*
(Down / Up Stream)
200m ->100/100Mbps 800m -> 79/80Mbps
400m -> 97/100Mbps 1000m -> 69/66Mbps
600m -> 86/91Mbps 1200m -> 60/52Mbps
