15
The MC252-1T-1CXP accepts IEEE 802.3at equipment for optimal power injection. Any
other Non-standard PoE Power devices may cause the MC252-1T-1CXP to malfunction.
Type 4 – MC252-1T-1CXP with PoE power input and MC252-1P-1CX with DC power output
CPE CO
MC252-1T-1CXP MC252-1P-1CX
Power Input
RJ-45 with 802.3at/af PoE input BNC with DC power over
coaxial input
Power Output
BNC with DC power over coaxial
output
DC Terminal block with 12V or
24V DC output
As the MC252-1T-1CXP is power over coaxial, please confirm
that other Non-PoE equipment is not connected with the
coaxial cable. When you connect the coaxial cable with
coax-LAN converter, CCTV camera, etc, it might cause other
equipment to damage.
