5
1.2 Product Features
Physical Port

Ports
Model Name
Copper BNC
MC252-1T-1CXP 1 x 10/100Base-TX (PoE IN) Power/Data Transmitter
MC252-1P-1CX 1 x 10/100Base-TX (PoE OUT) Power/Data Receiver
Power over Ethernet
 Eliminates Power cabling with PoE over Coaxial
 Ethernet over coaxial up to 1km with RG59U/RG6 75 Ohm Low Loss cable
 Complies with IEEE 802.3af / IEEE 802.3at Power over Ethernet on RJ-45 ports
 Supports PoE Power up to 30.8 watts (Vary on Power Source and Coaxial Distance)
 Auto detect powered device (PD) (MC252-1P-1CX)
Layer 2 Features
 Supports Auto-negotiation and 10/100Mbps half / full duplex and 1000Mbps full duplex mode
 Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x PAUSE frame flow
control (Full-Duplex)
VDSL2 Features
 Master / Slave selectable via DIP Switch
 Defines Asymmetric (Band Plan 998) and Symmetric band plans for the
transmission of Upstream and Downstream signals
Industrial Case / Installation
 Supports extensive LED indicators for network diagnostics
 IP30 metal case protection
 Compact size, DIN Rail and Wall Mount Design
 Power Input: External DC or PoE power input
 Supports EFT protection 2000 VDC for power line
 Supports 2000 VDC Ethernet ESD protection
 -40 to 75 degrees C operating temperature
