Page 7
Location 190 S S c c h h e e d d u u l l e e 1 1 C C l l o o s s i i n n g g T T i i m m e e (2 segments - numerical data)
This location contains the closing time of Schedule 1. Segment 1 contains the hour of the closing time
in 24-hour format. (1:00 PM = 13) Segment 2 contains the minutes after the hour of the closing
time.
Location 191 Schedule 1 Days (1 segment -feature selection data)
Use the following table to program the “days” for Schedule 1.
Location 192 Schedule 1 Function (1 segment - numerical data)
Schedule 1 controls any one of the 32 X-10 Output functions previously entered in locations 49
through 176. Program a number from 1 to 32 corresponding to the output you desire for Schedule 1.
See corresponding output “Special Functions”, options #4 (closed schedule) and #5 (open schedule).
Locations 193 - 316 Schedules 2 - 32 Function (1 segment - numerical data)
These locations contain Schedules 2 though 32. Each Schedule has four locations, which program the
Opening Time, Closing Time, Days and Function respectively. For example, Schedule 2 is programmed
in locations 193 through 196; and Schedule 32 is programmed in locations 313 through 316. Refer to
instructions of locations 189 – 192, and programming worksheets for more details.
PROGRAMMING EXAMPLES
EXAMPLE 1: TURNS ON ENTRYWAY LIGHT UPON
ENTRY ONLY DURING NIGHT. Have output #1 trip
and activate an X-10 module with house code C and
unit code 4 for 6 minutes when zone 1 is faulted only
from 5:00PM to 9:00AM, program the following:
EXAMPLE 2: TURNS A DEVICE ON OR OFF DURING
BUSINESS HOURS. Have output #5 trip and activate
an X-10 module with a house code of P and a unit code
of 8 from 9:00AM to 5:00PM Monday through Friday,
but not at all on Saturday or Sunday, program the
following:
LOC SEGMENT LOC SEGMENT
1 2 3 4 1 2 3 4
50 42 1 6 66 52 0 0
51 1 67 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
52 3 2 1 0 68 7 15 1 0
189 9 0 205 9 0
190 17 0 206 17 0
191 1
2
3
4
5
6
7
8
LED DESCRIPTION LED DESCRIPTION
1 “ON” if the schedule is active on Sunday 5 “ON” if the schedule is active on Thursday
2 “ON” if the schedule is active on Monday 6 “ON” if the schedule is active on Friday
3 “ON” if the schedule is active on Tuesday 7 “ON” if the schedule is active on Saturday
4 “ON” if the schedule is active on Wednesday 8 Reserved
