“OPERATOR” TERMINAL DESCRIPTION


TERMINAL

DESCRIPTION

POS

Connect to the KP POS terminal of the control panel. This terminal
supplies power to the NX-540E board.

COM

Connect to the KP COM terminal of the control panel. This terminal
supplies the common side of the power to the NX-540E board.

DATA

Connect to the KP DATA terminal of the control panel. This is the
data-signaling terminal to all the devices on the buss.

NC

Normally closed dry contact rated 1 Amp at 30
Volts.

COM

Common dry contact rated 1 Amp at 30 VDC.

NO

Normally open dry contact rated 1 Amp at 30
Volts.

Relay follows

X-10 Output

Function 3.

02

Open collector output that switches to GND when activated –
capable of up to 100mA. This output follows X-10 Output Function 2.

NOTE: If device is connected to output, it must see the transition

from 13V to GND. Part # 8915 can be used to connect to output.

01

Same as above. This output follows X-10 Output Function 1.

R1

(R1) House Telephone Ring (gray)

T1

(T1) House Telephone Tip (brown)

R

Connect to R1 on control panel

T

Connect to T1 on control panel
