Location 179 Feature and Partition Select (3 segments -feature selection data)
Segment 1 contains special features that can be enabled with the “Operator”. Factory defaults are
“off”.
1 = “ON” allows remote programming.
2 = “ON” enables emergency keys (Fire, Medical, and Panic).
3 = Reserved
4 = “ON” enables 2-call answering machine defeat.
5 = “ON” enables wait for answer machine on external access.
6 – 8 = Reserved
Segment 2 Reserved
Segment 3 selects the partitions that can be accessed through the “Operator”. The factory default
is all eight partitions “on”.
1 = Partition 1
2 = Partition 2 3 = Partition 3
4 = Partition 4 5 = Partition 5
6 = Partition 6 7 = Partition 7
8 = Partition 8
Location 180 “Operator” Menu (3 segments-feature selection
data)
Segment 1 contains the functions that are to be included in the “Operator” MENU. This location also
enables the partition functions, as well as the Home Control menu. NOTE: If any of the items 2, 3, 4,
6, 7,or 8 listed below are disabled, they will still perform as usual; they will simply not be included in
the MENU. However, functions 1 and 5 will NOT perform if they are disabled. Factory defaults are
“on”.
1 = Enables “Change Area” function ( r 1).
2 = Includes “Alarm Memory” function ( r 3) in MENU.
3 = Includes “Test Siren” function ( r 4) in MENU.
4 = Includes “Change Codes” function ( r 5) in MENU. Note: PINS for users 100-240 cannot
be programmed through the “Operator”.
5 = Enables “Home Control” function ( r 6).
6 = Includes “Reset Smoke Detector” function ( r 7) in MENU.
7 = Includes “Program System” function ( r 8) in MENU.
8 = Include “Set Time” function ( r 9 7) in MENU.
Segment 2 is used to enable/disable the Home Control functions. Factory defaults are “on”.
1 = Enables “Lights Off” function ( r 6 0) and “Lights On” function (r 6 1).
2 = Enables “Thermostat Control” function ( r 6 2).
Segment 3 Reserved
Location 181 X-10 Signals (1 segment – numerical data)
This location contains the number of times (0 – 15) the control panel will send an X-10 signal for
dimming or reliability purposes. The default is 1.
Location 182 Answer Machine Defeat Timer (1 segment – numerical data)
This location programs the number of seconds (0 – 15) the “Operator” is to listen for [#][#][#] to be
entered after the premise phone line is picked up. If the answering machine defeat is enabled in
Location 179, even if someone answers the phone the “Operator” is still waiting for the code. Factory
default is 3 seconds.
Locations 183 - 188 Reserved
Location 189 Schedule 1 Opening Time (2 segments - numerical data)
This location contains the opening time of Schedule 1. Segment 1 contains the hour of the opening
time in 24-hour format. (1:00 PM = 13) Segment 2 contains the minutes after the hour of the
opening time.
