EXITING THE PROGRAM MODE: When all the desired changes in programming have been made, it is
time to exit the Program Mode. Press [9][3][0][#] from a remote phone or [EXIT] [EXIT] from the
keypad.
LOADING THE FACTORY DEFAULTS
To load the factory defaults, enter the Program Mode using the procedure described above, then type
[9][1][0][#]. The loading takes approximately 10 seconds.
N
Load factory defaults: [9][1][0][#]
Exit program mode: [9][3][0][#] from remote phone or [EXIT] [EXIT] from keypad
ENROLLING
The NetworX control panels have the ability to automatically find and store in their memory the
presence of all keypads, zone expanders, wireless receivers and any other module connected to the
DATA terminal. This allows these modules to be supervised by the control panel. To enroll the
NetworX “Operator” module, enter the Program Mode as previously described. When the Program
Mode is exited, the NetworX control will automatically enroll the devices. The enrolling process takes
about 12 seconds, during which time the “Service” LED will illuminate. User codes will not be accepted
during the enrolling process. If a speaker is attached to the control panel, it will click at this time. If a
siren or bell is attached to the control panel, it will sound for about 1 second. Once a module is
enrolled, if it is not detected by the control, the “Service” LED will illuminate.
PROGRAMMING THE ZONES AND X-10 OUTPUTS
Location 0 Rings to Answer (2 segments - numerical data)
Segment 1 contains the number of rings the NetworX “Operator” will wait before answering the
telephone. Valid entries are 0-15, where 0 disables.
Segment 2 is Reserved.
Locations 1 - 48 Zone Descriptions (8 segments - numerical data)
These locations contain the programming data for voice descriptions (characteristics) of zones 1 - 48.
Each of the 48 locations/zones has a programmable message of 8 words maximum for each location.
The NX-540E is compatible with the NX-8E control panel. However, zones 49-192 do NOT
have custom zone descriptions. The interface module will simply state the zone number,
i.e. “Zone 49” to “Zone 192”.
Location 49 Output Description (8 segments - numerical data)
Location 49 contains the programmable data for voice description (characteristic) of X-10 Output #1.
This location allows a programmable message of 8 words maximum.
Location 50 Output Event/Zone/Time (3 segments - numerical data)
Location 50 is used to select the particular function, zone number and time for X-10 Output #1 to trip.
Segment 1 (EVENT) Selects the event that will trigger the X-10 output. Refer to the chart
on the next page for the specific events that can be selected.
Segment 2 (ZONE/USER) Selects the zone or user number necessary to trigger the X-10
output. If this location is programmed as a zero “0”, any zone or
user will activate the X-10 output.
Segment 3 (TIME) Selects the amount of time the X-10 output will remain activated
when triggered. If this location is programmed as a zero “0”, the X-
10 output will follow the particular event.
