NETWORX NX-540E “OPERATOR”
GENERAL DESCRIPTION
The NetworX “Operator” is a microcomputer controlled telephone interface module that may be added
to NetworX control panels. The “Operator” converts any TouchTone telephone to a system keypad and
allows system functions to be accessed via telephone on-premise or off-site. There are 48 separate
zone descriptions that may be programmed to fit the owner’s needs. In addition, the “Operator” will
control up to thirty-two X-10 modules (requires only one X-10 Pro PSC04 Interface Module per NetworX
system) with programmable descriptions for each. Each zone/output description is programmable using
the 182-word Library List found on page 8.
ACCESSING THE OPERATOR
FROM A PROTECTED SITE: The “Operator” may be accessed from any TouchTone phone. Press
[ r][r][r] to activate.
FROM AN OFF-SITE PREMISE: Call the phone number of the protected site. When the phone is
answered, press [#][#][#] within the first 8 seconds. If a person or device such as a fax/answering
machine answers the call, the “Operator” will come on the line when the person or machine hangs up.
Otherwise, the “Operator” will automatically answer the call after it hears a pre-designated number of
rings as programmed in location 0. The answering machine defeat function can be programmed in
location 179 on page 6. The “Operator” will prompt for a valid user code: “Please enter your code”.
N NOTE: These access codes (rrr and ###) are programmable and can be changed in locations 177
and 178. Refer to page 5.
ENTERING THE PROGRAM MODE: The program mode is accessed through the keypad of a
TouchTone phone by pressing [
r][8] once the “Operator” answers. The [r] accesses the main MENU,
and [8] accesses the programming mode.
If accessing from the protected site, the “Operator” will now prompt for a program code: “Enter
your code”. (Factory default code is [9][7][1][3]. You are now in the Program Mode and ready
to select the module to program.
If accessing from an off-site premise, when the “Operator” prompts for a code, enter the download
access code (Factory default code is 84800000). NOTE: Location 179 must be enabled for this
function.
The “Operator” will now prompt for the module: “Enter expander number followed by pound [#]”.
SELECTING THE MODULE TO PROGRAM: The module you are programming should be the first
entry. To program the “Operator”, enter [4][0][#]. The [4][0] is the module number of the
“Operator” and the [#] is the entry key. Other module numbers can be found in their corresponding
manuals.
The “Operator” will now prompt you for a location to program: “Enter location number followed by
pound [#]”.
PROGRAMMING A LOCATION: Once the number of the module has been entered, any programming
location can be accessed by directly entering the number of that specific location followed by [#].
EXITING A LOCATION: After the last segment of a location has been programmed, pressing [
r] will
exit that location. The [ r] key must be pressed or the data will not be saved. To exit before the last
segment, press [#]. As before, you are now ready to enter another programming location.
