X-10 OUTPUT 6 SPECIAL FUNCTIONS/PARTITIONS

Segment 1
‘ 1 = “ON” if output should time in minutes; “OFF” if output times in seconds.

‘ 2 = “ON” if output should latch until a code is entered.

‘ 3 = “ON” if output should reset if a code is entered while it is being

timed.

‘ 4 = “ON” if output should only trigger during a closed schedule.

‘ 5 = “ON” if output should only trigger during an open schedule

‘ 6 = “ON” if output should be inverted.

‘ 7 = “ON” if output should not be described in the menu.

Segment 2
‘ 1 = Partition 1

‘ 2 = Partition 2

‘ 3 = Partition 3

‘ 4 = Partition 4

‘ 5 = Partition 5

‘ 6 = Partition 6

‘ 7 = Partition 7

‘ 8 = Partition 8

X-10 OUTPUT 6 ADDRESS

Segment 1 = Module Number
Segment 2 = House Code
Segment 3 = X10 Function Code if ON
Segment 4 = X10 Function Code if OFF

5
0
1
0

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

73 X-10 OUTPUT 7 DESCRIPTION

108 7

74 X-10 OUTPUT 7 EVENT/ZONE/TIME

48 0 0

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

X-10 OUTPUT 7 SPECIAL FUNCTIONS/PARTITIONS

Segment 1
‘ 1 = “ON” if output should time in minutes; “OFF” if output times in seconds.

‘ 2 = “ON” if output should latch until a code is entered.

‘ 3 = “ON” if output should reset if a code is entered while it is being

timed.

‘ 4 = “ON” if output should only trigger during a closed schedule.

‘ 5 = “ON” if output should only trigger during an open schedule

‘ 6 = “ON” if output should be inverted.

‘ 7 = “ON” if output should not be described in the menu.

Segment 2
‘ 1 = Partition 1

‘ 2 = Partition 2

‘ 3 = Partition 3

‘ 4 = Partition 4

‘ 5 = Partition 5

‘ 6 = Partition 6

‘ 7 = Partition 7

‘ 8 = Partition 8

X-10 OUTPUT 7 ADDRESS

Segment 1 = Module Number
Segment 2 = House Code
Segment 3 = X10 Function Code if ON
Segment 4 = X10 Function Code if OFF

6
0
1
0

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

77 X-10 OUTPUT 8 DESCRIPTION

108 8

78 X-10 OUTPUT 8 EVENT/ZONE/TIME

48 0 0

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

X-10 OUTPUT 8 SPECIAL FUNCTIONS/PARTITIONS

Segment 1
‘ 1 = “ON” if output should time in minutes; “OFF” if output times in seconds.

‘ 2 = “ON” if output should latch until a code is entered.

‘ 3 = “ON” if output should reset if a code is entered while it is being

timed.

‘ 4 = “ON” if output should only trigger during a closed schedule.

‘ 5 = “ON” if output should only trigger during an open schedule

‘ 6 = “ON” if output should be inverted.

‘ 7 = “ON” if output should not be described in the menu.

Segment 2
‘ 1 = Partition 1

‘ 2 = Partition 2

‘ 3 = Partition 3

‘ 4 = Partition 4

‘ 5 = Partition 5

‘ 6 = Partition 6

‘ 7 = Partition 7

‘ 8 = Partition 8

X-10 OUTPUT 8 ADDRESS

Segment 1 = Module Number
Segment 2 = House Code
Segment 3 = X10 Function Code if ON
Segment 4 = X10 Function Code if OFF

7
0
1
0

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

81 X-10 OUTPUT 9 DESCRIPTION

108 9

82 X-10 OUTPUT 9 EVENT/ZONE/TIME

48 0 0

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
