LOC

DESCRIPTION

DEFAULT

DATA

X-10 OUTPUT 9 SPECIAL FUNCTIONS/PARTITIONS

Segment 1
‘ 1 = “ON” if output should time in minutes; “OFF” if output times in seconds.

‘ 2 = “ON” if output should latch until a code is entered.

‘ 3 = “ON” if output should reset if a code is entered while it is being

timed.

‘ 4 = “ON” if output should only trigger during a closed schedule.

‘ 5 = “ON” if output should only trigger during an open schedule

‘ 6 = “ON” if output should be inverted.

‘ 7 = “ON” if output should not be described in the menu.

Segment 2
‘ 1 = Partition 1

‘ 2 = Partition 2

‘ 3 = Partition 3

‘ 4 = Partition 4

‘ 5 = Partition 5

‘ 6 = Partition 6

‘ 7 = Partition 7

‘ 8 = Partition 8

X-10 OUTPUT 9 ADDRESS

Segment 1 = Module Number
Segment 2 = House Code
Segment 3 = X10 Function Code if ON
Segment 4 = X10 Function Code if OFF

8
0
1
0

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

85 X-10 OUTPUT 10 DESCRIPTION

108 10

86 X-10 OUTPUT 10 EVENT/ZONE/TIME

48 0 0

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

X-10 OUTPUT 10 SPECIAL FUNCTIONS/PARTITIONS

Segment 1
‘ 1 = “ON” if output should time in minutes; “OFF” if output times in seconds.

‘ 2 = “ON” if output should latch until a code is entered.

‘ 3 = “ON” if output should reset if a code is entered while it is being

timed.

‘ 4 = “ON” if output should only trigger during a closed schedule.

‘ 5 = “ON” if output should only trigger during an open schedule

‘ 6 = “ON” if output should be inverted.

‘ 7 = “ON” if output should not be described in the menu.

Segment 2
‘ 1 = Partition 1

‘ 2 = Partition 2

‘ 3 = Partition 3

‘ 4 = Partition 4

‘ 5 = Partition 5

‘ 6 = Partition 6

‘ 7 = Partition 7

‘ 8 = Partition 8

X-10 OUTPUT 10 ADDRESS

Segment 1 = Module Number
Segment 2 = House Code
Segment 3 = X10 Function Code if ON
Segment 4 = X10 Function Code if OFF

9
0
1
0

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

89 X-10 OUTPUT 11 DESCRIPTION

108 11

90 X-10 OUTPUT 11 EVENT/ZONE/TIME

48 0 0

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

X-10 OUTPUT 11 SPECIAL FUNCTIONS/PARTITIONS

Segment 1
‘ 1 = “ON” if output should time in minutes; “OFF” if output times in seconds.

‘ 2 = “ON” if output should latch until a code is entered.

‘ 3 = “ON” if output should reset if a code is entered while it is being

timed.

‘ 4 = “ON” if output should only trigger during a closed schedule.

‘ 5 = “ON” if output should only trigger during an open schedule

‘ 6 = “ON” if output should be inverted.

‘ 7 = “ON” if output should not be described in the menu.

Segment 2
‘ 1 = Partition 1

‘ 2 = Partition 2

‘ 3 = Partition 3

‘ 4 = Partition 4

‘ 5 = Partition 5

‘ 6 = Partition 6

‘ 7 = Partition 7

‘ 8 = Partition 8

X-10 OUTPUT 11 ADDRESS

Segment 1 = Module Number
Segment 2 = House Code
Segment 3 = X10 Function Code if ON
Segment 4 = X10 Function Code if OFF

0
1
0

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

93 X-10 OUTPUT 12 DESCRIPTION

108 12

94 X-10 OUTPUT 12 EVENT/ZONE/TIME

48 0 0

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
