Table 1.1 Event Table

#

Event

#

Event

#

Event

0

/

Burglary Alarm

17

Alarm Memory

35

Telephone Line Fault

1

/

Fire Alarm

18

Entry

36

Program Mode

2

/

24 Hour Alarm

19

Exit

37

Download

3

/

Zone Trouble

20

Entry or Exit

38

Ground Fault

4

/

Zone Tamper

21

Armed

39

Over Current

5

Burglary Siren

22

Not Armed

40

Box Tamper

6

Fire Siren

23

Ready

41

Siren Tamper

7

Any Siren

24

Not Ready

42

Any Zone Faulted

8

Zone Bypass

25

Fire

43

/

Any Alarm

9

AC Failure

26

Fire Trouble

44

Keypad Beeping

10

System Low Battery

27

Chime

45

/

Code Entry

11

/

Duress

28

/

Expander Trouble

46

:

Key FOB Function 1

12

/

Manual Fire

29

Dynamic Battery Test

47

:

Key FOB Function 2

13

/

Aux 2 Keypad

30

˜

Open Schedule

48

Follow X10 Command

14

/

Keypad Panic

31

˜

Closed Schedule

49

Flash X-10 for

Alarm Memory

15

Keypad Tamper

32

Listen In

50

Flash X-10 for Siren

16

/

Automatic Test

33

Line Seizure

51

Connected External

34

Failed to Communicate

52

Follow NX-540E Schedule


/ If set to follow condition, these events will be 1 second.

˜ See locations 52 & 53 in control panel.

: Events 46 & 47 require NX-408E, NX-416E, or NX-448E wireless receivers to operate.

Location 51

Special Functions / Partitions

(2 segments -feature selection data)

Segment 1 selects the following special conditions for X-10 Output #1:

LED 1 = “ON” if output should time in minutes; “OFF” if output times in seconds
LED 2 = “ON” if output should latch until a code is entered.
LED 3 = “ON” if output should reset if a code is entered while it is being timed. Default is “on”.
LED 4 = “ON” if output should only trigger during a closed schedule.
LED 5 = “ON” if output should only trigger during an open schedule
LED 6 = “ON” if output should be inverted.
LED 7 = “ON” if output should not be described in the menu.

Segment 2 selects the following partitions for X-10 Output #1. Factory default is “on”.

LED 1 = “ON” if the event should activate when it occurs in Partition 1.
LED 2 = “ON” if the event should activate when it occurs in Partition 2.
LED 3 = “ON” if the event should activate when it occurs in Partition 3.
LED 4 = “ON” if the event should activate when it occurs in Partition 4.
LED 5 = “ON” if the event should activate when it occurs in Partition 5.
LED 6 = “ON” if the event should activate when it occurs in Partition 6.
LED 7 = “ON” if the event should activate when it occurs in Partition 7.
LED 8 = “ON” if the event should activate when it occurs in Partition 8.
