IC Realtime IP High Speed PTZ Dome Camera with 36X Zoom and WDR (ICIPZ3601WDR) User Manual
Page 26
19
SCAN NO ： 001
SET LEFT LIMIT
SET RIGHT LIMIT
SCAN SPEED ：160
RUN
STOP
BACK
EXIT
z
Set preset: Set preset 26 or 92 to set scan left limit. Set preset 27 or 93 to set scan right limit. Set
preset 22 or 79 to begin record. Set preset 23 or 80 to stop record.
5.4.4.2 Pan
Move the cursor to PAN button and then click confirm button to go to setup interface.
z
PAN SPEED: Set dome rotation speed. Please use the left/right button on the keyboard or in the speed
dome terminal menu to set.
z
RUN: Move the cursor to call item and then click confirm button. The dome begins 360 degrees
continuous rotation.
z
STOP: Highlight stop item and then click confirm button. The dome stops rotation.
z
BACK: Go back to previous menu.
z
EXIT: Log out system menu.
5.4.4.3 Scan
Move the cursor to SCAN button and then click confirm button.
z
SCAN
NO
：Here is to set auto scan number. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
z
SET LEFT LIMIT
：Here is to set camera left address. Click confirm button to save current setup.
z
SET
RIGHT
LIMIT
：Here is to set camera right address. Click confirm button to save current setup.
z
SCAN SPEED: It is to set scan speed. Please use the left/right button on the keyboard or in the speed
dome terminal menu to set.
z
RUN: Please input auto scan number first, and then please move the cursor to RUN and click confirm
button to activate auto scan function.
z
STOP: Here is to terminate auto scan function.
z
BACK: Go back to previous menu.
z
EXIT: Log out system menu.
5.4.4.4 Cruise (Touring)
CRUISE NO： : 001
CRUISE SETTING
DELETE CRUISE
RUN
STOP
BACK
EXIT
PAN SPEED ：160
RUN
STOP
BACK
EXIT
