18
PRESET NO ：001
TITLE ：PRESET001
SETTING
CALL
BACK
EXIT
z AUTO SCAN: It is to set the speed dome scan number and scan speed. Move the cursor to SCAN and
then click confirm button to go to the third submenu.
z AUTO CRUISE: It is to set the cruise (tour) number and task. Move the cursor to AUTO CRUISE and
then click confirm button to go to the third submenu.
z AUTO PATTERN: It is to set the pattern number and etc. Move the cursor to PATTERN and then click
confirm button to go to the third submenu.
z IDLE FUNCTION: It is to set the idle movement and idle time. Move the cursor to IDLE FUNCTION and
then click confirm button to go to the third submenu.
z PRIVACY MASK: It is to set privacy mask number and etc. Move the cursor to current item and then
click confirm button to go to the third submenu.
z NEXT PAGE: It includes PTZ speed, set zero, power up, menu idle, PTZ auto stop, and heater. Move
the cursor to the item and then click the confirm button to set. .Click the confirm button to view rest
setting items.
z BACK: Go back to previous menu.
z EXIT: Log out system menu.
5.4.4.1 Preset Setup
Move the cursor to PRESET button and then click confirm button to go to set interface.
z
PRESET NO: Please use left/right key to modify preset number. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set. .
z TITLE ：Title text is the label used for you to identify the camera. System will automatically name a title
for the camera.
z SETTING: Please input preset number first and then select the monitor zone. Please move the cursor to
setting and click confirm button. The system will pop up a message: PRESET: ***. Here *** means
preset number. And the SETTING column pops up an OK. Now you successfully added a preset.
Please note, you need to enable display preset title function first (Main menu->display setting->preset
title).Repeat the above procedures to set more presets. Once you want to modify a preset, you can
input the preset number you want to modify and then follow the above steps to set the preset. You can
successfully modify a preset content.
z CALL: Here is to recall preset. Move the cursor to PRESET NO and then input corresponding preset
value. Then move the cursor to CALL and then click confirm button to go to a preset.
z BACK: Go back to previous menu.
z EXIT: Log out system menu.
For PELCO protocol user, please refer to the following special functions:
z
Call preset: Call preset 28 or preset 95 to go to dome menu. Call preset 29 or preset 99 to go to scan.
Call preset 24 or preset 81 to go to pattern. Call preset 25 or preset 82 to go to cruise (tour). Call preset
30 or preset 96 to stop scan or pattern. Call preset 31 or preset 83 to begin rotation. Call preset 33 to
enable PTZ 180 degrees rotation. Call preset 34 to set dome position as 0.
