14
z ADDR-SOFT: You can set address via software. It is to say, you can use menu to modify dome address.
The value ranges from 0 to 255. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
z BACK: Go back to the previous menu.
z EXIT: Log out system menu.
5.4.2 Display Setting
Move the cursor to DISPLAY SETUP and then click confirm button, you can go to the third submenu. Please
use the left/right button on the keyboard or in the speed dome terminal menu to set. After completed setup,
please click save button to save current setup.
z
PRESET TITLE: Display dome preset title or not. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set. You can go to Function Setup->Preset section to set
corresponding preset value and preset title.
z AZIMUTH DISP: Display dome current coordinates or not. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set
z POSITION: Display the angel between the benchmark and then current location. Please use the
left/right button on the keyboard or in the speed dome terminal menu to set.
z ZOOM DISP: Display speed dome zoom speed or not. Please use the left/right button on the keyboard
or in the speed dome terminal menu to set.
z INSIDE TEMPERATURE: Display dome internal temperature or not. There are three options: ℃/F/Off.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
z TITLE DISPLAY: Here you can set to display the speed dome title or not.
z BACK: Go back to the previous menu.
z EXIT: Log out system menu.
5.4.3 Camera Setting
Move the cursor to CAMERA SETTING and then click confirm button, you can go to the submenu.
z
WHITE BALANCE SETUP: It is to set the camera white balance mode. There are several options.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
z EXPOSURE SETTING: It is to set the camera exposure mode, gain and etc. Move the cursor to current
option and then click confirm button, you can go to the third menu.
PRESET TITLE ：ON
AZIMUTH DISP ：ON
POSITION ：OFF
ZOOM DISP ：OFF
INSIDE TEMP ：℃
TITLE DISP ：OFF
BACK
EXIT
WB SETTING
EXPOSURE SETTING
DAY/NIGHT SETTING
FOCUS MODE ：AUTO
FOCUS LIMIT : 30CM
ZOOM SPEED : 08
DIGITAL ZOOM : OFF
APERTURE : 09
NEXT PAGE
BACK
EXIT
