4
Please refer to Figure 2-1 for system cable connection.
Figure 2-1
2.3 Alarm Connection
You can refer to Figure 2-2 for detailed alarm connection information.
Figure 2-2
Network
Output Power
Input
Transformer
DVR
P C Power
Output
