12
Figure 2-2
2.1.3 3U series
The front panel of the 64-channel is shown as below. See Figure 2-3.
Figure 2-3
Please refer to the following sheet for front panel button information.
Name Icon Function
Power button
Power button, press this button for three seconds to boot up or
shut down DVR.
Number button 0-9
Input Arabic number
Switch channel
Input number
more than 10
-/--
If you want to input a number more than 10, please click this
button and then input.
In textbox, click this button to switch between numeral,
English(Small/Capitalized),donation and etc.
Shift
Enable or disable tour.
Activate current control, modify setup, and then move up and
down.
Increase/decrease numeral.
Up/
Down
S、T
Assistant function such as PTZ menu.
Shift current activated control, and then move left and right.
Left/
Right
W X
When playback, click these buttons to control playback bar.
ESC ESC Go to previous menu, or cancel current operation.
