146

Parameter Function

Latch

The alarm output can delay for the specified time after alarm stops.
Then system disables alarm and corresponding activation output.
The value ranges from 10s to 300s.

Send
email

If you enable this function, system can send out email to alarm the
specified user.

Alarm
upload

System can upload the alarm signal to the network (includes the alarm
centre.)

Show
message

System pops up the alarm messages in the monitor interface.

Buzzer

Once you check the box here, the buzzer beeps when an alarm
occurred.

7.5.3.8 Video Matrix

Here you can set tour channel and corresponding interval. See Figure 7-59.

Please note current product supports the 1-window spot tour.

Figure 7-59

7.5.3.9 Preview Control

Here you can set preview mode and preview channel. The window mod includes:1/4/8/9/16/25-
window. See Figure 7-60.
