IC Realtime Flex Series: 64 Channel 2CIF 3U Standalone DVR User Manual
Page 146
136
Parameter Function
Capture
You need to input capture channel number so that system can backup
snapshot file when alarm occurs.
Copy
It is a shortcut menu button. You can copy current channel setup to
one or more (all) channels.
Save
You can click save button after you complete setup for one channel,
or you can complete the whole setups and then click save button.
Refresh
Click this button to get device latest configuration information.
7.5.2.7 Detect
Analysis the video, system enable motion detection alarm when it detects the motion signal
reached the specified sensitivity.
The detection interface is shown as in Figure 7-48.
Figure 7-48
Figure 7-49
