IC Realtime Flex Series: 64 Channel 2CIF 3U Standalone DVR User Manual
Page 137
127
Parameter
Function
Parity
There are five options: none/odd/even/space/mark.
System default setup is:
z
Function:
Console.
z
Data bit: 8
z
Stop bit: 1
z
Baud bit: 115200
z
Parity:
None.
7.5.2.5 Network
Network interface is shown as in
X462H462H462H
Figure 7-37.
Figure 7-37
Please refer to the following sheet for detailed information.
Parameter
Function
IP Version
There are two options: IPv4 and IPv6. Right now, system
supports these two IP address format and you can access via
them.
MAC Address
The host in the LAN can get a unique MAC address. It is for
you to access in the LAN. It is read-only.
IP Address
Here you can use up/down button (ST) or input the
corresponding number to input IP address. Then you can set
the corresponding subnet mask the default gateway.
Subnet Prefix
The input value ranges from 0 to 128. It is to mark a specified
network MAC address. Usually it includes an organization of
multiple-level.
