Before starting to build, take an inventory of this kit to make sure it is complete, and inspect the parts to make sure they
are of acceptable quality. If any parts are missing or are not of acceptable quality, or if you need assistance with assembly,
contact Product Support. When reporting defective or missing parts, use the part names exactly as they are written in
the Kit Contents list.

Great Planes Product Support:

3002 N. Apollo Drive, Suite 1

Champaign, IL 61822

Telephone: (217) 398-8970, ext. 5

Fax: (217) 398-7721

E-mail:

[email protected]

KIT INSPECTION

Plastic Tree Parts
A1

Z-Bend Clevis (10)

A2

Offset Z-Bend Clevis (4)

B1

Stand-Alone Control Horn (5)

B2

Stand-Alone Control Horn Retainer (5)

C1

Clip Hinge Control Horn (5)

C2

Clip Hinge (26)

C3

Hinge Retainer Ring (10)

C4

Aileron Link Horn (4)

D1

Axle Support (2)

D2

Rod Support (12)

D4

Tailwheel Bracket (1)

D5

Tailwheel (1)

D6

Wheel Collar (2)

E1

Control Surface Brace (4)

E2

Fuselage Joiner (3)

E3

Pushrod Support (4)

F1

Wire Clip (4)

F2

Aileron Servo Mounting Tray (1)

F3

Fuselage Servo Mount (2)

F4

Fuselage Aileron Servo Mount (1)

G1 Double-Sided Offset Arm, Size B (2)
G2 Double-Sided Arm, Size B (2)
G3 Single-Sided Arm, Size B (4)
G4 Double-Sided Arm, Size A (2)
G5 Double-Sided Offset Arm, Size A (2)
G6 Single-Sided Arm, Size A (4)
G7 Double-Sided Arm, Size C (2)
G8 Double-Sided Offset Arm, Size C (2)
G9 Single-Aided Arm, Size C (4)

Carbon Rods & Tubes
Fuselage Doubler Tube 5.5 x 295 mm
Elevator Joiner Tube 3 x 216 mm

Rudder Post Tube 3 x 145 mm
Fuselage Main Tube 3 x 684 mm
Leading Edge Tube 3 x 650 mm (2)
Trailing Edge Tube 3 x 370 mm (4)
Landing Gear Rods 2 x 190 mm (2)
Wheel Axles 2 x 17 mm (2)
Rudder Pushrod 1 x 340 mm
Elevator Pushrod 1 x 370 mm
Aileron Pushrod 1 x 80 mm (2)
Aileron Link Pushrod 1 x 165 mm (2)

Other Parts
Firewall
O-rings
Top Wing Braces 2 x 115 mm (4)
Bottom Wing Braces 2 x 85 mm (2)

Kit Contents (Not Photographed)

KIT CONTENTS

Kit Contents

1.

Top Wing & Ailerons

2.

Bottom Wing & Ailerons

3.

Rudder

4.

Plywood Firewall

5.

Main Wheels

6.

Hook and Loop Material

7.

Upper Vertical Fuselage Half

8.

Lower Vertical Fuselage Half

9.

Propeller

10. Small Vertical Nose Doublers (2)
11. Prop Saver
12. Horizontal Fuselage Halves (L&R)
13. Interplane Struts (L&R)
14. Fuselage Braces (L&R)
15. Inner Wheel Pants (L&R)
16. Outer Wheel Pants (L&R)
17. Horizontal Nose Doublers (4)
18. Large Vertical Nose Doublers (2)
19. Horizontal Stabilizer w/Elevators

1

3

7

8

9

10

2

5

4

6

11

12

13

14

16

17

19

18

15
