2. Build the plane according to the instructions. Do not
alter or modify the model, as doing so may result in an
unsafe or unflyable model.

3. Use an R/C radio system and components that are in first-
class condition. The FlatOuts R/C Universe Bipe requires
specialized radio gear. Refer to

“DECISIONS YOU MUST

MAKE” to get an accurate description of the specialized
gear required.

4. You must properly install all R/C and other components so
that the model operates correctly on the ground and in the air.

5. You must test the operation of the model before every
flight to insure that all equipment is operating, and that the
model has remained structurally sound. Be sure to check
connectors often and replace them if they show signs of
wear or fatigue.

Remember: Take your time and follow directions to end
up with a well-built model that is straight and true.

If you’re not already an AMA (Academy of Model
Aeronautics) member, we highly recommend that you join.
In addition to providing liability protection while operating
under the AMA Safety Code, the AMA is the governing body
of model aeronautics in the United States and fights for your
rights as member of the modeling community. You must also
be an AMA member to fly at R/C clubs chartered by the
AMA–most of which are. Contact the AMA at the address or
toll-free phone number below.

WARNING!! Failure to follow all instructions could cause
permanent damage to the battery and its surroundings, and
cause bodily harm!

ONLY use a LiPo approved charger. NEVER use a
NiCd/NiMH peak charger!

NEVER charge in excess of 4.20V per cell.

ONLY charge through the “charge” lead. NEVER charge
through the “discharge” lead.

NEVER charge at currents greater than 1C.

ALWAYS set charger’s output volts to match battery volts.

ALWAYS charge in a fireproof location.

NEVER trickle charge.

NEVER allow the battery temperature to exceed
50°F (65°C).

NEVER disassemble or modify pack wiring in any way or
puncture cells.

NEVER discharge below 2.5V per cell.

NEVER place on combustible materials or leave
unattended during charge or discharge.

ALWAYS KEEP OUT OF REACH OF CHILDREN.

In the hands of a capable pilot, the FlatOuts R/C Universe
Bipe is an impressive 3D performer. But for the R/C Universe
Bipe to perform to its full potential, it must be properly
equipped with all the right gear (servos, batteries, receiver,
speed control). There may be more than one type and brand
of radio equipment that can be used, but based on extensive
testing, following is the equipment we recommend so you
can get the most performance out of your R/C Universe Bipe
and assemble it as shown in this instruction manual.

The FlatOuts R/C Universe Bipe performs extremely well
with the Great Planes RimFire

22M-1000 Brushless Motor

(GPMG4500) and it is the recommended motor for this
airplane. This manual covers the installation of the RimFire
motor and the plywood firewall included is designed
specifically for use with the RimFire. Other motors can be
used, however modification may be required for installation.

With a standard, four-channel radio, the FlatOuts R/C
Universe Bipe is capable of all the basic 3D maneuvers.
However, some advanced pilots who are already familiar
with handling “flat foamies” may prefer to fly this FlatOuts
with a computer radio capable of endpoint adjustments (for
fine-tuning control throws), exponentials (for “softening” the
throws near the center of the travel), and various mixing
functions (such as rudder-to-elevator mixing for extended
knife-edge flight).

The FlatOuts R/C Universe Bipe requires three

micro servos

with a maximum weight of 9g [.3 oz] each and a minimum
torque rating of 15 oz-in. Futaba

®

S3108 servos

Servos

Transmitter

Motor

DECISIONS YOU MUST MAKE

LITHIUM BATTERY HANDLING & USAGE

Academy of Model Aeronautics

5151 East Memorial Drive

Muncie, IN 47302

Tele: (800) 435-9262

Fax (765) 741-0057

Or via the Internet at:

http://www.modelaircraft.org

Note: We, as the kit manufacturer, provide you with a top
quality kit and great instructions, but ultimately the quality
and flyability of your finished model depends on how you
build it; therefore, we cannot in any way guarantee the
performance of your completed model, and no
representations are expressed or implied as to the
performance or safety of your completed model.

3
