4
❍
Great Planes 10x4.5 PowerFlow ™ Propeller
(GPMQ6660) (draws 15 amps max.)
❍ Great Planes 3.5mm Male/2.5mm Female Bullet
Connector Adapter (GPMM3122)
Battery Pack & Accessories
The following battery packs are recommended.
❍ Great Planes LiPo 1600mAh BP Series 11.1V 20C
Discharge w/ Balance (GPMP0719)
❍
Great Planes LiPo 1500mAh Power Series 11.1V 25C
Discharge w/ Balance (GPMP0511)
A LiPo-compatible charger is required for these batteries,
along with a cell balancer. We recommend:
❍
Great Planes Equinox ™ 1-5 cell LiPo cell balancer
(GPMM3160)
❍ Great Planes PolyCharge4 ™ LiPo battery charger
(GPMM3015)
OR
❍
Great Planes PolyCharge DC LiPo battery charger
(GPMM3010)
Required Adhesive and
Building Supplies
This is the list of adhesive and building supplies required to
fi nish the PT-19 EP.
❍ 1/2 oz. [15g] Thin Pro ™ CA (GPMR6001)
❍
1/2 oz. [15g] Medium Pro CA+ (GPMR6007)
❍
4oz [113g] Pro 6-minute epoxy (GPMR6042)
❍ 4oz [113g] Pro 30-minute epoxy (GPMR6043)
❍
R/C-56 Glue 4oz (JOZR5007)
❍
Denatured alcohol
❍ Drill bits: #55 [1.3mm] [1.3mm], 1/16" [1.6mm],
5/64" [2mm], 1/8" [3.2mm]
❍ #1 Hobby knife (HCAR0105)
❍
#11 blades (5-pack, HCAR0211)
❍
Hobbico Steel T-Pins 1" (100) (HCAR5100)
❍ Great Planes Pro Thread locker (GPMR6060)
❍
CA applicator tips (HCAR3780)
❍
220 grit sandpaper
❍ Masking tape (TOPR8018)
❍
Bru Line hemostat – curved 5-1/2" (BRUR1303)
❍
Fabric Tape Measure (HCAR0478)
Optional Supplies and Tools
Here is a list of optional tools mentioned in the manual that
will help you build the PT-19 EP.
❍
21 st Century ® sealing iron (COVR2700)
❍ 21 st Century iron cover (COVR2702)
❍
2 oz. [57g] spray CA activator (GPMR6035)
❍
4 oz. [113g] aerosol CA activator (GPMR634)
❍
Epoxy brushes (6, GPMR8060)
❍ Mixing sticks (50, GPMR8055)
❍
Mixing cups (GPMR8056)
❍
Great Planes ® Hook and Loop material (GPMQ4480)
❍ 1/2" [13mm] double-sided foam mounting tape
(GPMQ4440)
❍
Excel Small Hobby Clamps (2) 1" x 3.5" [25 x 89mm]
(EXLR5663)
❍ CA debonder (GPMR6039)
❍
Great Planes Double-Sided Servo Tape 1"x 3’
(GPMQ4442)
❍ Panel Line Pen (TOPQ2510)
❍ Rotary tool (Dremel ® ) with cutoff wheel
❍
Hobbico ® Flexible 18" Ruler Stainless Steel (HCAR0460)
❍
Builder’s Triangle Set (HCAR0480)
❍ AccuThrow ™ Defl ection Gauge (GPMR2405)
❍
Hobbico 12 Volt DC power supply (HCAP0250)
❍
Acrylic paint and paint brushes for painting pilot (found at
craft stores)
Pilot Figure (optional)
The following pilot fi gures are suggested. Note: The
pre-painted pilot listed below is slightly larger than the
recommended Williams Brothers pilot fi gure and is a WWI
pilot.
❍
Williams Brothers 1/8-Scale Pilot Kit Standard
(WBRQ1040)
OR
❍
Great Planes Small EP WWI Pilot, Pre-Painted
(GPMA2998)
IMPORTANT BUILDING NOTES
●
When you see the term test fi t in the instructions, it means
that you should fi rst position the part on the assembly
without using any glue, then slightly modify or custom fi t
the part as necessary for the best fi t.
