System Resources Screen
2E48-27R/2E49-27R User’s Guide 5-47
5.13 SYSTEM RESOURCES SCREEN
The System Resources screen, Figure 5-21 , provides information
concerning the processor used in the 2E4X-27R and the amount of
FLASH memory, DRAM, and NVRAM that is installed and how much of
that memory is available. This screen also allows the user to monitor the
current processor (switch) utilization and the peak switch utilization.
To access the System Resources screen from the Device Specific
Configuration Menu screen, use the arrow keys to highlight the SYSTEM
RESOURCES menu item and press ENTER. The System Resources
screen displays.
Figure 5-21 System Resources Screen
The following briefly defines each field of the System Resources screen.
CPU Type (Read-only)
Indicates the microprocessor used in the 2E4X-27R.
Firmware Revision: XX.XX.XX
System Resources
23142-23
Device Type: 2E48-27R
BOOTPROM Revision: XX.XX.XX
Flash Memory Installed: 4 MB
DRAM Installed: 16 MB
NVRAM Installed: XX KB
Available: XXXXX Bytes
Available: XXXXX Bytes
Available: XXXXX Bytes
CPU Type: i960 HT 25 Mhz
Current Switch Utilization: 66%
Peak Switch Utilization: 75%
Reset Peak Switch Utilization: [NO]
2E48-27R LOCAL MANAGEMENT
Event Message Line
SAVE
RETURN
RETURN EXIT
