Chapter 5: Local Management

5-42

2E48-27R/2E49-27R User’s Guide

5.11

ETHERNET FULL DUPLEX CONFIGURATION
SCREEN

The Ethernet Full Duplex Configuration screen,

Figure 5-19

, allows the

user to set ports 1 through 24, individually or all at once, to either
Standard Ethernet or Full Duplex operation, and monitor each port to see
whether or not it is enabled and linked to another 10BASE-F device.
Refer to

Section 5.15

to set the Operation Mode for ports 25 and 26.

To access the Ethernet Full Duplex Configuration screen from the Device
Configuration Menu screen, use the arrow keys to highlight the
ETHERNET FULL DUPLEX CONFIGURATION menu item and
press ENTER. The Ethernet Full Duplex Configuration screen displays.

Figure 5-19

Ethernet Full Duplex Configuration Screen

This section explains each field of the Full Duplex Configuration screen.

PORT # (Read-only)

Identifies the number of the port.

Firmware Revision: XX.XX.XX

Ethernet Full Duplex Configuration

23141-21

Device Type: 2E48-27R

BOOTPROM Revision: XX.XX.XX

PORT #

LINK STATUS

Link

No Link

Link

2E48-27R LOCAL MANAGEMENT

Event Message Line

SAVE

OPERATION MODE

[STANDARD ENET]

PORT STATUS

ENABLED

SET ALL PORTS: [FULL]

RETURN

[13-24]

EXIT
