Descriptions of Available Connections
USB PORT
Linking with USB flash disk for remote data transfer.
TCP/IP PORT
Connect with a CAT 5 cable for LAN connection, one end to terminal’s port and
another end to the computer’s TCP/IP Port.
TCP/IP for Single Connection
Linking the terminal to a single computer using TCP/IP
requires Ethernet 10/100Base-T Crossover Cable. The
cable can be used to cascade hubs or to connect Ether-
net stations back-to-back without a hub. It works with
both 10Base-T and 100Base-TX.
TCP/IP for Network Connection
Linking the terminals to multiple computers using TCP/IP requires Ethernet 10/100Base-T Straight Thru
Cable or “whips”. The cable works with both 10Base-T and 100Base-TX, connecting a network interface
card to a hub or network outlet.
POWER SUPPLY PORT
Insert the Power Adapter point to this port for power.
RS485/WIEGAND INPUT CONNECTION PORT
RS485 Single Connection: Connection to a single computer using RS485 wire.
RS485 Network Connection: Connection to multiple computers using Daisy Chain connection.
Wiegand Output: Connecting with third party connector or terminal(s).
CONNECTOR PIN CABLE COLOR CONNECTOR
TX+ 1 • White/Orange • 1 TX+
TX- 2 • Orange • 2 TX-
RX+ 3 • White/Green • 3 RX+
4 • Blue • 4
5 • White/Blue • 5
RX- 6 • Green • 6 RX-
7 • White/Brown • 7
8 • Brown • 8
