PR 100A and probe 3 with the expansion DR 100A); connect PR 100A with DR
100A by using a twisted pair
(2) provide the probe with a protection able to protect it against contacts with metal
parts or use insulated probes.
2 TECHNICAL DATA
2.1 Technical data
Box: self-extinguishing grey.
Size: 71 x 90 x 58 mm (2.79 x 3.54 x 2.28 in, 4 DIN modules).
Installation: on DIN rail (it is not supplied by the builder).
Frontal protection: IP 40.
Connections: extractable terminal blocks with pitch 10 mm (0.39 in) for cables up to
2.5 mm² (0.38 sq in, power supply) and with pitch 5 mm (0.19 in) for cables up to
2.5 mm² (0.38 sq in, inputs and recorder).
Ambient temperature: from 0 to 55 °C (32 to 131 °F, 10 ... 90% of relative humidity
without condensate).
Power supply: 110-240 Vac, 50/60 Hz, 2 VA (standard) or 12-36 Vac/dc, 50/60 Hz,
2 VA (by request).
Measure inputs: 4 for, by using the recorder PR 100A, for PTC or NTC probes, “J” or
“K” thermocouples, 2 wires Pt 100 probes, 4-20 mA current transducers.
At terminal 17 there are 12 Vdc you can use in order to supply the transducers.
