9 WORKING SETPOINTS AND CONFIGURATION PARAMETERS
9.1 Working setpoints
MIN. MAX. U.M. DEF. WORKING SETPOINTS
r1 r2 °C/°F (1) 0.0 working setpoint
9.2 Configuration parameters
PARAM. MIN.
MAX. U.M. DEF. WORKING SETPOINTS
SP r1 r2 °C/°F (1) 0.0 working setpoint
PARAM. MIN. MAX. U.M. DEF. MEASURE INPUTS
CA1 -25.0 25.0 °C/°F (1) 0.0 cabinet probe offset
CA2 -25.0 25.0 °C/°F (1) 0.0 auxiliary probe offset (only if P4 = 1 or 2)
P0 0 1 - - - 1 kind of probe
0 = PTC
1 = NTC
P1 0 1 - - - 1 decimal point Celsius degree (for the quantity to show during the normal operation)
1 = YES
P2 0 1 - - - 0 unit of measure temperature (2)
0 = °C
1 = °F
P4 0 3 - - - 3 second input function
0 = input not enabled
1 = measure input (evaporator probe)
2 = measure input (condenser probe)
3 = digital input (multipurpose/door switch input)
P5 0 2 - - - 0 quantity to show during the normal operation
0 = cabinet temperature
1 = working setpoint
2 = temperature read by the auxiliary probe (only if P4 = 1 or 2)
PARAM. MIN. MAX. U.M. DEF. MAIN REGULATOR
r0 0.1 15.0 °C/°F (1) 2.0 working setpoint differential
r1 -99.0 r2 °C/°F (1) -50.0 minimum working setpoint
r2 r1 99.0 °C/°F (1) 50.0 maximum working setpoint
r3 0 1 - - - 0 locking the working setpoint modification (with the procedure related in paragraph 3.1; 1 = YES)
r4 0.0 99.0 °C/°F (1) 0.0 temperature increase during function Energy Saving (only if P4 = 3 and i0 = 0); also look at i5
PARAM. MIN. MAX. U.M. DEF. COMPRESSOR PROTECTIONS
C0 0 240 min 0 compressor delay since you turn on the instrument
C1 0 240 min 5 minimum time between two activations in succession of the compressor; also compressor delay since
the end of the cabinet probe error (3)
C2 0 240 min 3 minimum time the compressor remains turned off
C3 0 240 s 0 minimum time the compressor remains turned on
C4 0 240 min 10 time the compressor remains turned off during the cabinet probe error; also look at C5
C5 0 240 min 10 time the compressor remains turned on during the cabinet probe error; also look at C4
C6 0.0 199.0 °C/°F (1) 80.0 condenser temperature above which the overheated condenser alarm is activated (only if P4 = 2) (4)
C7 0.0 199.0 °C/°F (1) 90.0 condenser temperature above which the compressor locked alarm is activated (only if P4 = 2)
C8 0 15 min 1 compressor locked alarm delay (only if P4 = 2) (5)
PARAM. MIN. MAX. U.M. DEF. DEFROST
d0 0 99 h 8 defrost interval; also look at d8 (6)
0 = the defrost at intervals will never be activated
d2 -99.0 99.0 °C/°F (1) 2.0 defrost cutoff temperature (only if P4 = 1)
d3 0 99 min 30 defrost duration if P4 = 0, 2 or 3; defrost maximum duration if P4 = 1
0 = the defrost will never be activated
d4 0 1 - - - 0 defrost when you turn on the instrument
1 = YES
d5 0 99 min 0 defrost delay when you turn on the instrument (only if d4 = 1); also look at i5
d6 0 1 - - - 1 temperature shown during the defrost
0 = cabinet temperature
1 = if to the defrost activation the cabinet temperature is below “working setpoint + r0”, at most “work-
ing setpoint + r0”; if to the defrost activation the cabinet temperature is above “working setpoint +
r0”, at most the cabinet temperature to the defrost activation (7)
d8 0 2 - - - 0 kind of defrost interval
0 = the defrost will be activated when the instrument will have remained turned on the time d0
1 = the defrost will be activated when the compressor will have remained turned on the time d0
2 = the defrost will be activated when the evaporator temperature will have remained below the tem-
perature d9 the time d0 (only if P4 = 1) (8)
d9 -99.0 99.0 °C/°F (1) 0.0 evaporator temperature above which the count of the defrost interval is suspended (only if P4 = 1 and
d8 = 2)
PARAM. MIN. MAX. U.M. DEF. TEMPERATURE ALARMS
A0 0 1 - - - 0 temperature joined to the lower temperature alarm
0 = cabinet temperature
1 = temperature read by the auxiliary probe (only if P4 = 1 or 2) (9)
A1 -99.0 99.0 °C/°F (1) -10.0 temperature below which the lower temperature alarm is activated; also look at A0 and A2 (4)
A2 0 2 - - - 1 kind of lower temperature alarm
0 = alarm not enabled
1 = relative to the working setpoint (or "working setpoint - A1”; consider A1 without sign)
2 = absolute (or A1)
A3 0 1 - - - 0 temperature joined to the upper temperature alarm
0 = cabinet temperature
1 = temperature read by the auxiliary probe (only if P4 = 1 or 2) (9)
A4 -99.0 99.0 °C/°F (1) 10.0 temperature above which the upper temperature alarm is activated; also look at A3 and A5 (4)
A5 0 2 - - - 1 kind of upper temperature alarm
0 = alarm not enabled
1 = relative to the working setpoint (or "working setpoint + A4”; consider A4 without sign)
2 = absolute (or A4)
A6 0 240 min 120 upper temperature alarm delay since you turn on the instrument (only if A3 = 0)
A7 0 240 min 15 temperature alarm delay
A8 0 240 min 15 upper temperature alarm delay since the end of the defrost (only if A3 = 0) (10)
A9 0 240 min 15 upper temperature alarm delay since the deactivation of the door switch input (only if P4 = 3 and
i0 = 3) (11)
PARAM. MIN. MAX. U.M. DEF. DIGITAL INPUTS (only if P4 = 3)
i0 0 3 - - - 3 kind of digital input
0 = MULTIPURPOSE INPUT - in this case look at parameters i1, i5, i7, i8 and i9
1 = RESERVED
2 = RESERVED
3 = DOOR SWITCH INPUT - in this case look at parameters i1, i2 and i3; the activation of the input will
turn off the compressor (at most the time i3 or as long as the input will be deactivated) (12)
i1 0 2 - - - 0 kind of contact digital input
0 = NO (input active if you close the contact)
1 = NC (input active if you open the contact)
2 = input not enabled
i2 -1 120 min 30 delay to signal the door switch input alarm
-1 = no signal
i3 -1 120 min 15 maximum duration of the effect provoked by the activat. of the door switch input (-1 = the effect will last
as long as the input will be deactivated)
i5 0 5 - - - 3 effect provoked by the activation of the multipurpose input
0 = no effect
1 = SYNCHRONIZING THE DEFROSTS - spent the time d5 the defrost will be activated (13)
2 = ACTIVATING THE ENERGY SAVING - function Energy Saving will be activated (as long as the input
will be deactivated); also look at r4 (13)
3 = ACTIVATING THE EXTERNAL ALARM - spent the time i7 the display will show the code “iA” flashing
and the buzzer will be activated (as long as the input will be deactivated)
4 = ACTIVATING THE MANOSTAT - the compressor will be turned off, the display will show the code “iA”
flashing and the buzzer will be activated (as long as the input will be deactivated); also look at i7, i8
and i9
5 = TURNING OFF THE INSTRUMENT - the instrum. will be turned off via software (as long as the input
will be deact.); also look at C0, d4 and A6
i7 0 120 min 0 if i5 = 3, delay to signal the multipurpose input alarm
if i5 = 4, compressor delay since the deactivation of the multipurpose input (14)
i8 0 15 - - - 0 number of multipurpose input alarms such as to provoke the instrument locked alarm (only if i5 = 4)
0 = alarm not enabled
i9 1 999 min 240 time without multipurpose input alarms in order that the alarm counter is cleared (only if i5 = 4)
PARAM. MIN. MAX. U.M. DEF. VARIOUS
t0 0 1 - - - 0 turning on/off the instrument (via software) by hand through button
1 = YES
t1 0 1 - - - 0 kind of data to be counted (15)
0 = compressor working days
1 = instrument working days (16)
t2 0 1,999 d 100 if t1 = 0, number of compressor working days above which service is requested
if t1 = 1, number of instrument working days above which service is requested
0 = function not enabled
PARAM. MIN. MAX. U.M. DEF. SERIAL NETWORK (MODBUS)
LA 1 247 - - - 247 instrument address
Lb 0 3 - - - 2 baud rate
0 = 2,400 baud
1 = 4,800 baud
2 = 9,600 baud
3 = 19,200 baud
LP 0 2 - - - 2 parity
0 = none
1 = odd
2 = even
PARAM. MIN. MAX. U.M. DEF. RESERVED
E9 0 1 - - - 1 reserved
(1) the unit of measure depends on parameter P2
(2) set the parameters related to the regulators appropriately after the modification of the parameter P2
(3) if parameter C1 has value 0, the delay since the end of the cabinet probe error will however be 2 min
(4) the differential of the parameter is 2.0 °C/4 °F
(5) if (when you turn on the instrument) the condenser temperature is above the one you have set with parameter C7, parameter C8 will have
no effect
(6) the instrument stores the count of the defrost interval every 30 min; the modification of parameter d0 has effect since the end of the previous
defrost interval or since the activation of a defrost by hand
(7) the display restores the normal operation as soon as the defrost ends and the cabinet temperature falls below the one that has locked the
display (or if a temperature alarm arises)
(8) if parameter P4 has value 0, 2 or 3, the instrument will work as if parameter d8 had value 0
(9) if parameter P4 has value 0 or 3, the instrument will work as if parameter had value 0
(10) during the defrost the temperature alarms are not enabled, on condition that they have arisen after the activation of the defrost
(11) during the activation of the door switch input the upper temperature alarm is not enabled, on condition that it has arisen after the activation
of the input
(12) the compressor is turned off spent 10 s since the activation of the input
(13) the effect is not signalled
(14) make sure the time you have set with parameter i7 is shorter than the one you have set with parameter i9
(15) erase the working days after the modification of parameter t1
(16) the instrument counts the working days also when it is turned off via software.
