11 CONFIGURATION PARAMETERS
11.1 First level configuration parameters
PARAM. MIN. MAX. U.M. DEF. TIMER
t1 00:00 (1) (2) 00:00 duration time t1
t2 00:00 (1) (3) 00:00 duration time t2 (not visible if instrument code = 3 or 4)
t3 00:00 (1) (4) 00:00 duration time t3 (not visible if instrument code = 1, 2, 3 or 4)
t4 00:00 (1) (5) 00:00 duration time t4 (visible if instrument code = 7 or 8)
t5 00:00 99:59 min:s 00:05 duration of the activation of the buzzer (not visible if instrument code = 4 or 9)
t6 00:00 99:59 min:s 00:00 time between the activation of the buzzer and the shutdown of the last load (not visible if instrument
code = 3, 4 or 9)
t7 0 2 - - - 1 times base time t1 (6)
0 = s:ds
1 = min:s
2 = h:min
t8 0 2 - - - 1 times base time t2 (not visible if instrument code = 3 or 4) (6)
0 = s:ds
1 = min:s
2 = h:min
t9 0 2 - - - 1 times base time t3 (not visible if instrument code = 1, 2, 3 or 4) (6)
0 = s:ds
1 = min:s
2 = h:min
t10 0 2 - - - 1 times base time t4 (visible if instrument code = 7 or 8) (6)
0 = s:ds
1 = min:s
2 = h:min
t19 00:00 (1) (7) 00:00 time between the activation of load 2 and the shutdown of load 1 (visible if instrument code = 5 or 6)
11.2 Second level configuration parameters
PARAM. MIN. MAX. U.M. DEF. TIMER
t1 00:00 (1) (2) 00:00 duration time t1
t2 00:00 (1) (3) 00:00 duration time t2 (not visible if instrument code = 3 or 4)
t3 00:00 (1) (4) 00:00 duration time t3 (not visible if instrument code = 1, 2, 3 or 4)
t4 00:00 (1) (5) 00:00 duration time t4 (visible if instrument code = 7 or 8)
t5 00:00 99:59 min:s 00:05 duration of the activation of the buzzer (not visible if instrument code = 4 or 9)
t6 00:00 99:59 min:s 00:00 time between the activation of the buzzer and the shutdown of the last load (not visible if instrument
code = 3, 4 or 9)
t7 0 2 - - - 1 times base time t1 (6)
0 = s:ds
1 = min:s
2 = h:min
t8 0 2 - - - 1 times base time t2 (not visible if instrument code = 3 or 4) (6)
0 = s:ds
1 = min:s
2 = h:min
t9 0 2 - - - 1 times base time t3 (not visible if instrument code = 1, 2, 3 or 4) (6)
0 = s:ds
1 = min:s
2 = h:min
t10 0 2 - - - 1 times base time t4 (visible if instrument code = 7 or 8) (6)
0 = s:ds
1 = min:s
2 = h:min
t11 0 2 - - - 0 event provoking the start of the count (not visible if instrument code = 3)
0 = pressure of button
or activation of input start
1 = pressure of button
2 = activation of input start
t12 0 2 - - - 0 event provoking the stop of the count (not visible if instrument code = 3) (8)
0 = pressure of button
or activation of input stop
1 = pressure of button
2 = activation of input stop
t13 0 1 - - - 0 kind of contact input start
0 = NO (the input will be active if you close the contact)
1 = NC (the input will be active if you open the contact)
t14 0 1 - - - 0 kind of contact input stop (not visible if instrument code = 3)
0 = NO (the input will be active if you close the contact)
1 = NC (the input will be active if you open the contact)
t15 0 1 - - - 0 kind of count
0 = remaining time (count down)
1 = elapsed time (count up)
t16 0 3 - - - 0 display colour
0 = green
1 = red
2 = green when the loads will be turned off and red when the loads will be turned on
3 = red when the loads will be turned off and green when the loads will be turned on
t17 0 2 - - - 0 action provoked by the events you have set with parameters t11 and t12 when the count is running
(not visible if instrument code = 3)
0 = the event you have set with parameter t12 will stop the count and the event you have set with
parameter t11 will start it again from the beginning
1 = the event you have set with parameter t12 will suspend the count and the event you have set with
parameter t11 will start it again from the beginning
2 = the event you have set with parameter t12 will suspend the count and the event you have set with
parameter t11 will resume it
t18 0 1 - - - 0 cyclical operation (visible if instrument code = 2, 5 or 8)
1 = YES
t19 00:00 (1) (7) 00:00 time between the activation of load 2 and the shutdown of load 1 (visible if instrument code = 5 or 6)
t20 0 1 - - - 0 locking the modification of parameter t1 (with the procedure related in paragraph 6.3)
1 = YES
t21 0 1 - - - 0 locking the modification of parameter t2 (with the procedure related in paragraph 6.3; not visible if
instrument code = 3 or 4)
1 = YES
t22 0 1 - - - 0 locking the modification of parameter t3 (with the procedure related in paragraph 6.3; not visible if
instrument code = 1, 2, 3 or 4)
1 = YES
t23 0 1 - - - 0 locking the modification of parameter t4 (with the procedure related in paragraph 6.3; visible if instru-
ment code = 7 or 8)
1 = YES
t24 0 1 - - - 1 load 1 status during a suspension of the count that happens when the load is turned on (not visible if
instrument code = 3 or 4)
0 = turned off
1 = tuned on
t25 0 1 - - - 1 load 2 status during a suspension of the count that happens when the load is turned on (not visible if
instrument code = 1, 2, 3, 4 or 9)
0 = turned off
1 = tuned on
t26 0 3 - - - 0 operation of the instrument to the restoration of the power supply after a lack that arises when the
count is running
0 = the count will be stopped
1 = the count will be stopped, the display will flash and the buzzer will be activated intermittent (this last
the time t27)
2 = the count will be started again since the beginning of the time during which the lack of power
supply will have arisen, the display will flash and the buzzer will be activated intermittent (this last
the time t27) (9)
3 = the count will be resumed since the moment in which the lack of power supply will have arisen
(with a maximum error of 60 s), the display will flash and the buzzer will be activated intermittent
(this last the time t27) (9) (10)
t27 00:00 15:00 min:s - -:- - time the buzzer is activated (intermittent) to the restoration of the power supply after a lack that arises
when the count is running
- - : - - = as long as it is silenced by hand
PARAM. MIN. MAX. U.M. DEF. SERIAL NETWORK (MODBUS)
LA 1 247 - - - 247 instrument address
Lb 0 3 - - - 2 baud rate
0 = 2,400 baud
1 = 4,800 baud
2 = 9,600 baud
3 = 19,200 baud
LP 0 2 - - - 2 parity
0 = none
1 = odd
2 = even
PARAM. MIN. MAX. U.M. DEF. RESERVED
E9 0 1 - - - 1 reserved
PARAM. MIN. MAX. U.M. DEF. INSTRUMENT CODE
CFG 1 (11) - - - (12) instrument code (13)
(1) the value depends on the times base (parameters t7, t8, t9 and t10):
(2) the unit of measure depends on parameter t7
(3) the unit of measure depends on parameter t8
(4) the unit of measure depends on parameter t9
(5) the unit of measure depends on parameter t10
(6) the modification of the parameter provokes the cancellation of the value of the corresponding time
(7) if the instrument code has value 5, the unit of measure will depend on parameter t7; if the instrument code has value 6, the unit of measure
will depend on parameter t8
(8) pressure of button 4 s provokes however the stop of the count
(9) if the lack arises during a suspension of the count, to the restoration of the power supply the count will be suspended to the moment in
which the lack of power supply will have arisen
(10) only if the times base of the time during which the lack of power supply has arisen is mn:s or h:min, otherwise the instrument will work as
if parameter t26 had value 2
(11) the value depends on the kind of instrument (4 for EVK721 and 9 for EVK722)
(12) the value depends on the kind of instrument (1 for EVK721 and 5 for EVK722)
(13) the modification of the parameter provokes the cancellation of the value of parameters t1, t2, t3, t4 and t19; to restore the default value of
the parameters, look at paragraph 6.1.
The instrument must be disposed according to the local legislation about the collection for electrical and electronic equipment.
TIMES BASE
s:ds
min:s
h:min VALUE
99:90
99:59
99:59
