ALARMS
7.1
Alarms
Code Meaning
tiME Alarm temperature controlled blast chilling or tem-
perature controlled blast freezing not concluded
within the maximum duration (HACCP alarm)
AL
Low temperature alarm
AH
High temperature alarm (HACCP alarm)
id
Open door alarm
HP
High pressure alarm
PF
Lack of power supply alarm (HACCP alarm; only in
the model EVXV812 and in the model EVXV815)
COH Overheated condenser alarm
CSd
Locked compressor alarm
ESt
Alarm download of the configuration parameters not
successfully completed
CEr
Alarm firmwares of the configuration parameters
contained in EVKEY not coinciding with that of the
device
Erd
Alarm upload of the configuration parameters not
successfully completed
8
Errors
8.1
Errors
Code Meaning
Pr1
Room probe error
Pr2
Needle probe error
Pr3
Evaporator probe error
Pr4
Condenser probe error
rtc
Real time clock error (only in the model EVXV812
and in the model EVXV815)
9
TECHNICAL DATA
9.1
Technical data
Purpose of the devices: controllers for blast chillers.
Execution: open frame board.
Size:
-
63.8 x 110.0 x 45.8 mm (2.511 x 4.330 x 1.803 in;
W x H x D) for EVXV802 and EVXV812
-
63.8 x 110.0 x 50.3 mm (2.511 x 4.330 x 1.980 in;
W x H x D) for EVXV805 and EVXV815.
Installation: by back panel, with M3 threaded studs.
Index of protection: IP00.
Connections: faston 6.3 mm (0.248 in) wide (power supply
and outputs), fixed screw terminal block (inputs), 6 poles con-
nector (serial port).
Operating temperature: from 0 to 55 °C (from 32 to
131 °F).
Storage temperature: from -25 to 60 °C (from -13 to 140
°F).
Operating humidity: from 10 to 90% of relative humidity
not condensing.
Pollution situation: 2.
Power supply:
-
230 VAC (±10%), 50 / 60 Hz, 2.3 VA max. or 115 VAC
(±10%), 50 / 60 Hz, 2.3 VA max. in EVXV802 and in
EVXV812
-
230 VAC (±10%), 50 / 60 Hz, 2.8 VA max. or 115 VAC
(±10%), 50 / 60 Hz, 2.8 VA max. in EVXV805 and in
EVXV815.
Overvoltage category: III.
Real time clock:
-
not available in EVXV802 and in EVXV805
-
incorporated (with capacitor) in EVXV812 and in EVXV815.
Battery autonomy in the event of lack of power supply:
24 h with battery fully charged.
Battery charging time: 2 min (the battery is charged by the
power supply of the device).
Signaling and alarm buzzer: incorporated.
Analog inputs: 3 inputs (room probe, needle probe and evapo-
rator probe), which can be set via configuration parameter for
PTC / NTC probes.
PTC analog inputs (990 Ω @ 25 °C, 77 °F)
Kind of sensor:
KTY 81-121.
Working range:
from -50 to 150 °C (from -58 to
302 °F).
Resolution:
0.1 °C (1 °F).
Protection:
none.
NTC analog inputs (10K Ω @ 25 °C, 77 °F)
Kind of sensor:
ß3435.
Working range:
from -40 to 105 °C (from -40 to
220 °F).
Resolution:
0.1 °C (1 °F).
Protection:
none.
Digital inputs: 1 input (door switch), which can be set via
configuration parameter for normally open / normally closed
contact (free of voltage contact, 5 VDC, 2 mA).
5.4
Soft blast freezing and storing
To start the cycle operate as follows:
1.
Make sure the device is in status “on”.
2.
Make sure the keyboard is not locked and no proce-
dure is running.
3.
Press and release button BLAST FREEZING: LED
,
LED
, LED HARD and LED
will flash; ac-
cording to the model, press and release button BLAST
CHILLING again to start the cycle time controlled.
4.
Press and release button HARD / SOFT: LED HARD
will switch off.
5.1 According to the model, the display will show the work-
ing setpoint during the blast freezing or the blast freez-
ing cut off temperature.
5.2 Press and release button UP or button DOWN in 15 s
to modify these values.
6.
Press and release button START / STOP: LED
and
LED
will firmly remain switched on and it will be
started the test for the verification of the proper in-
sertion of the needle probe.
6.1 If the test is successfully completed, the cycle will be
started.
6.2 If the test is not successfully completed, the cycle will
be started time controlled.
To stop the cycle operate as follows:
7.
Press and release button START / STOP.
5.5
Starting the precooling
To start the precooling operate as follows:
1.
Make sure the device is in status “on”.
2.
Make sure no procedure is running.
3.
According to the model, switch on the device or press
and hold button BLAST CHILLING 1 s: LED will flash.
To stop the precooling operate as follows:
4.
Press and hold button BLAST CHILLING 1 s or start an
operating cycle.
5.6
Switching on the UV light for the cycle of
sterilization (only in the model EVX805 and
in the model EVX815)
Operate as follows:
1.
Make sure the function is enabled.
2.
Make sure the device is in status “on” and the door is
closed, or the door switch input is not active.
3.
Make sure the keyboard is not locked and no proce-
dure is running.
4.
Press and hold button AUXILIARY 1 s: LED AUX will
switch on.
5.7
Needle probe heating (only in the model
EVX805 and in the model EVX815)
Operate as follows:
1.
Make sure the function is enabled.
2.
Make sure the device is in status “on” or a storing is
running and the door is open, or the door switch input
is active.
3.
Make sure the keyboard is not locked and no proce-
dure is running.
4.
Press and hold button AUXILIARY 1 s: LED
will
flash and LED AUX will switch on.
6
SIGNALINGS AND INDICATIONS
6.1
Signalings
LED
Meaning
LED blast chilling
LED blast freezing
HARD LED hard blast chilling / blast freezing
LED temperature controlled blast chilling / tem-
perature controlled blast freezing
LED time controlled blast chilling / time control-
led blast freezing
LED storing
LED defrost
LED precooling
AUX LED auxiliary (only in the model EVXV805 and in
the model EVXV815)
HACCP LED HACCP
°C
LED Celsius degree
°F
LED Fahrenheit degree
min
LED minutes
LED on / stand-by
6.2
Indications
Code Meaning
Loc
The keyboard is locked; look at paragraph “Lock-
ing / unlocking the keyboard”
UnL
The keyboard has been unlocked; look at para-
graph “Locking / unlocking the keyboard”
