5
❍ 6-Minute Pro
™ Epoxy (GPMR6045)
❍ Trim Seal Tool
™ (TOPR2200)
❍ Heat Gun (TOPR2000)
❍ Straightedge (Fourmost Non-Slip,
FORR2149)
❍ Denatured or Isopropyl Alcohol (for epoxy
clean-up)
❍ Spare Glow Plugs (O.S. #8 for most
2-stroke engines, OSMG2691)
❍ HobbyLite
™ Balsa Filler (HCAR3401)
❍ Epoxy Brushes (GPMR8060)
❍ CA Debonder (GPMR6039)
❍ Powered hand tool with Sanding Drum and
Cut-off Wheel
❍ Bar Sander or Sanding Block and
Sandpaper (coarse, medium, fi ne grit)*
*A fl at, durable, easy-to-handle sanding tool is
a necessity for building model airplanes. Great
Planes makes a complete range of Easy-Touch
™
Bar Sanders and replaceable Easy-Touch
adhesive-backed sandpaper. For the Butterfl y all
that is required is the short 5-1/2" Bar Sander
(GPMR6169) and two assortment packages of
adhesive-backed sandpaper (GPMR6189).
For future reference, here’s a list of Easy-Touch
Bar Sanders and adhesive-backed sandpaper:
5-1/2" Bar Sander (GPMR6169)
11" Bar Sander (GPMR6170)
22" Bar Sander (GPMR6172)
12’ Roll of adhesive-backed sandpaper,
80-grit (GPMR6180)
150-grit (GPMR6183)
220-grit (GPMR6185)
Assortment pack of 5-1/2" strips (GPMR6189)
Building Notes
● There are two types of screws used in this kit:
Sheet metal screws are
designated by a number
and a length.
For example #6 x 3/4"
Machine screws are
designated by a number,
threads per inch and a
length.
For example 6-32 x 3/4"
● When you see the term “test fi t” in the instructions,
it means you should fi rst position the part on the
assembly
without using any glue, then slightly
modify or “custom fi t” the part as necessary for
the best fi t.
● Whenever just “epoxy” is specifi ed you may
use either 30-minute epoxy or 6-minute epoxy.
When 30-minute epoxy is specifi ed it is highly
recommended that you use only 30-minute epoxy
because you will need either the working time
and/or the additional strength.
Common Abbreviations
Fuse = Fuselage
Stab = Horizontal Stabilizer
LE = Leading edge (front)
TE = Trailing edge (rear)
Ply = Plywood
" = Inches
