DLE 20 - Manual (Page 21)

21
Replacement Parts
Stock
No.
Key
No. Description
DLEG2001 1 Cylinder
DLEG2002 2 Crankshaft
DLEG2003 3 Crankcase
22 Back Plate
DLEG2004 4 Piston
27 Wrist Pin
28 C-Clips
DLEG2005 5 Piston Ring
DLEG2006 6 Electronic Ignition Module
DLEG2007 7 Muffl er
19 Muffl er Gasket
DLEG2008 8 Carburetor Complete
DLEG2009 9 Connecting Rod
DLEG2011 11 Reed Valve Assembly
21 Carburetor Block
DLEG2012 25 Front Bearing Set
12 Rear Bearing Set
DLEG2013 13 Electronic Ignition Sensor
DLEG2014 14 Back plate O-Ring
DLEG2015 15 Screw Set
DLEG2016
Propeller Drive Hub Assembly
16 Thrust Washer
24 Prop Washer
DLEG2017 26 Needle Bearing For Connecting Rod
DLEG2018
Gasket Set
17 Carburetor Block Gasket
18 Carburetor Gasket
19 Muffl er Gasket
20 Head Gasket
30 Reed Valve Gasket
DLEG2019 29 Woodruff Key
DLEG2020 23 Propeller Jam Nuts (2)
DLEG2021 32 Spark Plug Cap
DLEG5510 10 Spark Plug
Optional Parts
DLEG5525 Digital Tachometer (See page 17)
