DLE 20 - Manual

DLE-20
Operator’s Manual
Specifications
20cc [1.2 cu. in.]
2.5 HP / 9,000 rpm
1,700 rpm
Electronic Ignition
14u10, 15 u8, 16u6, 16u8, 17u6
CM6
(Gap) 0.018in.– 0.020 in. [0.45mm – 0.51mm]
1.26 in. [32mm] u0.98 in. [ 25 mm]
10.5 :1
DLE MP 148 100424 with Manual Choke
Main Engine − 1.43 lb [ 650 g ]
Muffler − 1.76 oz [50 g]
Electronic Ignition − 4.23 oz [120 g]
87− 93 Octane Gasoline with a 30:1
gas/2-stroke (2-cycle) oil mixture
Displacement:
Performance:
Idle Speed:
Ignition Style:
Recommended Propellers:
Spark Plug Type:
Diameter × Stroke:
Compression Ratio:
Carburetor:
Weight:
Fuel:
© 2011 Hobbico ® , Inc. DLEG0020 Mnl 1.1
™
