DLE-30
Operator’s Manual
Specifications
30.5 cc [1.86 cu. in.]
3.7HP / 8,500 rpm
1,600 rpm
Electronic Ignition
18u8, 18u10, 19u8, 20u8
CM6
(Gap) 0.018in.– 0.020 in. [0.45mm – 0.51mm]
1.41in. [36mm] u1.18 in. [ 30 mm]
7.6:1
DLE with Manual Choke
Main Engine − 2 lb [ 910 g ]
Muffler − 2.11oz [60 g]
Electronic Ignition − 4.23oz [120 g]
Engine Mount Standoffs − 0.71oz [20 g]
87− 93 Octane Gasoline with a 30:1
gas/2-stroke (2-cycle) oil mixture
Displacement:
Performance:
Idle Speed:
Ignition Style:
Recommended Propellers:
Spark Plug Type:
Diameter × Stroke:
Compression Ratio:
Carburetor:
Weight:
Fuel:
