2
Parts List
(1) DLE-20cc Gas Engine w/DLE MP 148 100424
(1) DLE Spark Plug (NGK CM6 size) with additional spring
(1) Muffl er with gasket
(2) 4 x 14 mm SHCS (muffl er mounting)
(1) Electronic Ignition Module with additional tachometer lead
(1) Silicone Pick-up Wire Cover / Ignition Wire Cover
(1) Red Three Pin Connector Lead with Pig Tail (ignition switch)
(1) Long Throttle Arm Extension with installation screw and nut
(2) Three Pin Connector Securing Clips
(1) DLE Decal (not pictured)
Safety Tips and Warnings
● This engine is not a toy. Please place your safety and the safety
of others paramount while operating. DLE will not be held
responsible for any safety issues or accidents involving this engine.
● Operate the engine in a properly ventilated area.
● Before starting the engine, please make sure all components
including the propeller and the engine mount are secure and
tight. It is strongly recommended that a screw sealant is used
(Great Planes ® Threadlocker GPMR6060) during engine installation.
● During the break-in period, it is recommended that the engine be
installed on the aircraft or a test stand with an appropriate shock
absorber. Otherwise it is probable that vibration could rebound
back to the engine and serious damages may occur during the
break-in period.
