Cerebot MX3cK Reference Manual

www.digilentinc.com

page 23 of 23

Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.

1

JA-08

5

RE05

PMD5/RE5

2

JA-09

6

RE06

PMD6/RE6

3

JA-10

7

RE07

PMD7/RE7

58

N/A

42

RF00

RF0

PIN_LED1, (LD4)

59

N/A

43

RF01

RF1

PIN_LED2, (LD5)

34

JB-03

10

RF02

U1RX/SDI1/RF2

33

JB-02

9

RF03

U1TX/SDO1/RF3

31

JC-03

18

RF04

PMA9/U2RX/SDA2/CN17/RF4

32

JC-02

17

RF05

PMA8/U2TX/SCL2/CN18/RF5

35

JB-04

11

RF06

U1RTS/BCLK1/SCK1/INT0/RF6

37

J2-1,J2-2

41

RG02

SCL1/RG2

36

J2-3,J2-4

40

RG03

SDA1/RG3

4

JE-04

35

RG06

SCK2/PMA5/CN8/RG6

5

JE-03

34

RG07

SDI2/PMA5/CN8/RG7

JP6 in M position

6

JE-02

33

RG08

SDO2/PMA3/CN10/RG8

JP8 in M position

8

JE-01

32

RG09

SS2/PMA2/CN11/RG9

7

N/A

N/A

MCLR

9

N/A

N/A

VSS

10

N/A

N/A

VDD

19

N/A

N/A

AVDD

20

N/A

N/A

AVSS

25

N/A

N/A

VSS

26

N/A

N/A

VDD

38

N/A

N/A

VDD

41

N/A

N/A

VSS

56

N/A

N/A

VCAP/VDDcore

57

N/A

N/A

ENVREG
