Cerebot MX3cK Reference Manual

www.digilentinc.com

page 21 of 23

Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.

13

JE-10

39

RB03

C2IN+/AN3/CN5/RB3

A10

36

J2-3,J2-4

40

RG03

SDA1/RG3

37

J2-1,J2-2

41

RG02

SCL1/RG2

58

N/A

42

RF00

RF0

PIN_LED1, (LD4)

59

N/A

43

RF01

RF1

PIN_LED2, (LD5)

7

N/A

N/A

MCLR

9

N/A

N/A

VSS

10

N/A

N/A

VDD

17

N/A

N/A

RB06

PGEC2/AN8/OCFA/RB6

18

N/A

N/A

RB07

PGED2/AN7/RB7

19

N/A

N/A

AVDD

20

N/A

N/A

AVSS

25

N/A

N/A

VSS

26

N/A

N/A

VDD

38

N/A

N/A

VDD

39

N/A

N/A

RC12

OSC1/CLKI/RC12

X1, system clock
oscillator

40

N/A

N/A

RC15

OSC2/CLKO/RC15

X1, system clock
oscillator

41

N/A

N/A

VSS

47

N/A

N/A

RC13

SOSCI/CN1/RC13

X2, secondary oscillator

48

N/A

N/A

RC14

SOSCO/T1CK/CN0/RC14

X2, secondary oscillator

56

N/A

N/A

VCAP/VDDcore

57

N/A

N/A

ENVREG

23

N/C

N/C

RB10

TMS/CVREFOUT/PMA13/AN10/RB10

24

N/C

N/C

RB11

TDO/PMA12/AN11/RB11

30

N/C

N/C

RB15

PMALL/PMA0/AN15/OCFB/CN12/RB15
